Samsung Hvac AJ012TNNDCH/AA Wind-Free Mini 4-Way Cassette 12K BTU 2.0 (JNH12NDT)

Product Description

The SAMSUNG HVAC AJ012TNNDCH/AA Wind-Free Mini 4-Way Cassette is a multi-zone heat pump indoor unit. This deluxe mini 4-way cassette features electronic expansion valve temperature control and is designed for wall mount installation. The unit has a cooling capacity of 11900 BTU/Hour and a heating capacity of 13000 BTU/Hour.

• Horizontal discharge airflow
• Low ambient control built in
• Auto-restart after power loss

Product Highlights

This unit features a galvanized steel frame, ETL approval for Canada and US, and a BLDC fan type. It operates on 208 to 230 Volt AC power.

Product Information

Standard Information

• Brand: SAMSUNG HVAC
• Manufacturer Part Number: AJ012TNNDCH/AA

Technical Specifications

• Approval: ETL (Canada and US)
• Brand Name: Wind-Free
• Category: HVAC/R & Fans
• Cooling Capacity: 11900 BTU/Hour
• Current Rating: 0.52 Amp (Running Current), 0.17 Amp Full Load (Fan)
• Frequency Rating: 60 Hertz
• Number Of Phases: 1
• Power Rating: 65 Watt (Fan Motor)
• Series/Model: FJM
• Temperature Control Type: Electronic Expansion Valve
• Type: Mini 4-Way Cassette, Deluxe
• Voltage Rating: 208 to 230 Volt AC
• Enclosure Material: Galvanized Steel (Frame)
• Heating Capacity: 13000 BTU/Hour
• Refrigerant Type: R-410A
• Airflow Rating: 371 CFM
• Sound Level: 35 Decibel (Fan)
• Pipe Connection: 1/4 Inch (Liquid), 3/8 Inch (Suction), 1 Inch Inner Diameter Drain, 1-1/4 Inch Outer Diameter Drain
• Fan Type: BLDC
• Includes: Filter
• Application: Light Commercial and Residential
• Make: Samsung
• Manufacturer: Samsung HVAC
• Model code: AJ012TNNDCH/AA
• Power: 10,000 ~ 15,000 BTU/H
