Samsung db96-15733a Evaporator Assembly Unit

Product Description

The SAMSUNG db96-15733a is an evaporator assembly unit designed for use in Samsung mini-split or ductless air conditioning systems. The evaporator assembly serves as the indoor heat exchange component, absorbing heat from the conditioned space and transferring it to the refrigerant circuit. This part is a direct OEM replacement, making it the correct choice when the original evaporator coil or its integrated housing has failed or developed a leak. Licensed HVAC technicians are the appropriate trade for sourcing and installing this component.

This evaporator assembly unit is suited for residential and light-commercial ductless split system applications. It is intended for installation within the indoor air handler where it functions as the primary cooling coil. Replacement is typically required following refrigerant-side corrosion, coil damage, or persistent leak-down faults traced to the indoor unit. No specific compatible model numbers were provided in the available product data.

Key Features

• OEM Samsung evaporator assembly for direct factory-spec replacement
• Designed for integration into Samsung indoor air handler units
• Functions as the primary heat exchange coil in the refrigerant circuit
• Engineered to original dimensional and flow specifications for proper fitment

Compatibility

Designed as an OEM-style replacement evaporator assembly for Samsung ductless mini-split indoor air handler units. Consult the Samsung parts catalog or the original equipment documentation to confirm fitment with a specific model before ordering.

Installation Notes

Installation of an evaporator assembly must be performed by an EPA Section 608 certified HVAC technician. The refrigerant system must be properly recovered before disassembly, and the system must be evacuated and recharged to manufacturer specifications after the new assembly is seated. Power to the indoor and outdoor units must be fully disconnected at the disconnect or breaker before any service work begins. Do not attempt to braze or modify the refrigerant connections without the appropriate tools and trade certifications.

Technical Specifications

• Component Type: Evaporator Assembly Unit
• System Type: Ductless Mini-Split Air Conditioning

Standard Information

• Brand: SAMSUNG
• Manufacturer Part Number: db96-15733a
