S&C Electric 64080R1 Universal Fuse Link 80 Amp (23 Inch)

Product Description

S&C Electric 64080R1 is a 23 inch universal fuse link rated 80 A with a standard speed characteristic for distribution protection. The link is rated for 7.2 - 27 kV systems, carries revision R1, and has manufacturer resistance test results of 0 mΩ. It is a utility-grade fuse link designed for medium-voltage distribution protection in overhead and pad-mounted transformer circuits.

• 80 A amperage rating; voltage rating 7.2 - 27 kV.
• Standard speed curve; universal 23 inch length; revision R1.
• Manufacturer resistance test: 0 mΩ; intended for distribution protection.

Product Highlights

23 inch universal fuse link, 80 A, standard speed, 7.2 - 27 kV, revision R1

Product Information

Standard Information

• Brand: S&C ELECTRIC
• Manufacturer Part Number: 64080R1

Technical Specifications

• Manufacturer: S&C Electric
• Manufacturer Part Number: 64080R1
• Manufacturer Catalog Number: 64080R1
• Irby Part Number: 3506409
• Product Type: Universal fuse link
• Class/Type: Fuse Link
• Voltage Rating: 7.2 - 27 kV
• Amperage: 80 A
• Length: 23 in
• Speed Curve: Standard speed
• Revision: R1
• Application: Distribution protection
• Color Options: Dark blue, green, orange, red, tan
