Rwc 24634LF 1/2 in Push-to-connect Brass Gate Valve

Product Description

The RWC 24634LF is a 1/2-inch SharkBite-style push-to-connect gate valve constructed from forged brass and designed for quick, tool-free installation on potable water supply systems. The valve connects to 1/2-inch pipe on both ends using a push-fit mechanism that eliminates the need for soldering, glue, unions, or specialty tools. Its multi-turn gate design allows precise regulation of water flow rather than simple on/off shutoff. The one-piece forged brass body delivers long-term durability under normal residential and light commercial service conditions. An integrated drain vent port is built into the valve body to support cold-weather maintenance and freeze protection. Licensed plumbers and experienced pipefitters are the primary installers of this fitting.

This gate valve is suited for residential and light commercial plumbing applications where a tool-free, push-to-connect solution is required. It is compatible with any combination of copper, PEX, CPVC, or PE-RT pipe, making it highly versatile across mixed-material plumbing systems. Typical install scenarios include main supply lines, branch shutoffs, and retrofit work where access is limited and soldering is not practical or permitted.

Key Features

• Push-to-connect ends accept copper, PEX, CPVC, or PE-RT pipe with no solder, glue, or additional tools required
• Multi-turn gate valve design allows controlled regulation of water flow
• One-piece forged brass body provides structural strength and corrosion resistance
• Integrated drain vent supports cold-weather maintenance and freeze protection
• Lead-free construction suitable for potable water applications as indicated by LF designation

Compatibility

Compatible with any combination of 1/2-inch copper, PEX, CPVC, or PE-RT pipe. No additional adapters or fittings are required when transitioning between compatible pipe materials at this valve.

Installation Notes

Installation should be performed by a licensed plumber in accordance with local plumbing codes and IPC requirements. Shut off the water supply and relieve system pressure before cutting into any existing line and installing this valve. Ensure pipe ends are cut square, deburred, and clean before insertion into the push-fit fitting to achieve a proper seal. Do not exceed the pressure and temperature ratings for the pipe type being used on either side of the valve.

Technical Specifications

• Connection Type: Push-to-Connect (SharkBite-style)
• Inlet Size: 1/2 inch
• Outlet Size: 1/2 inch
• Valve Type: Gate Valve (Multi-Turn)
• Body Material: Forged Brass
• Compatible Pipe Types: Copper, PEX, CPVC, PE-RT
• Weight: 0.505 pounds
• UPC: 00697285246348

Standard Information

• Brand: RWC
• Manufacturer Part Number: 24634LF
