Rwc 22463LFA Sharkbite 1 in Cf X 1 in Cf Brass Pex Ball Valve

Product Description

The RWC 22463LFA is a full-port brass ball valve designed for PEX tubing installations using the SharkBite barb connection system. It accepts 1-inch crimp-fit (CF) connections on both ends and delivers unrestricted flow through its full-port design. The valve body is constructed from DZR (dezincification resistant) brass, which resists the corrosion and mineral leaching common in potable water systems. Licensed plumbers and water distribution installers use this valve where a reliable, manually operated shutoff is required in a PEX-based supply line. NSF certification confirms it meets standards for contact with potable water.

This valve is suited for residential and light commercial water distribution systems where PEX tubing is the primary pipe material. It is typically installed at branch shutoff points, fixture isolation locations, or service connections. The barb connection format makes it compatible with standard PEX crimp tooling and copper crimp rings or stainless steel clamp rings, giving installers flexibility in fastening method. It is appropriate for both hot and cold water supply lines.

Key Features

• Full-port design allows unrestricted flow with minimal pressure drop across the valve
• DZR brass construction resists dezincification and general corrosion in potable water service
• 1-inch crimp-fit (CF) connections on both ends for use with standard PEX crimp tooling
• NSF-listed for use in potable water distribution systems
• Quarter-turn ball valve operation for fast, positive shutoff

Compatibility

Designed as an OEM-style replacement or new-installation valve for 1-inch PEX water distribution systems using crimp-fit barb connections.

Installation Notes

Installation should be performed by a licensed plumber in accordance with local plumbing codes and IPC requirements. Shut off the water supply and relieve system pressure before cutting into any existing line. Use a calibrated PEX crimp tool with the appropriate copper or stainless steel rings to secure the barb connections and verify crimp dimensions with a go/no-go gauge after installation. Do not overtighten or use pipe thread sealants on the barb ends.

Technical Specifications

• Connection Size: 1 inch x 1 inch
• Connection Type: Crimp-Fit (CF) barb, both ends
• Port Type: Full port
• Body Material: DZR brass
• Certification: NSF listed
• Weight: 0.674 pounds
• Sold As: Each

Standard Information

• Brand: RWC
• Manufacturer Part Number: 22463LFA
