Rw Beckett pf20322u Clean Cut Oil Pump with Solenoid

Product Description

The RW BECKETT pf20322u is a single-stage Clean Cut oil pump with an integrated solenoid valve, developed in collaboration with Suntec Industries. It delivers up to 4 gallons per hour at 100 psi and operates at a rated speed of 3600 RPM. The solenoid valve cuts oil flow almost instantly when power to the motor is interrupted, eliminating coasting stops that can cause soot formation on shutdown. Fewer moving parts and fewer external oil fittings reduce the potential for leaks and service calls. Licensed HVAC and oil-burner technicians install this pump on oil-fired heating appliances.

This pump is suited for residential and light commercial oil-fired burner applications where clean shutdown performance is a priority. Its design eliminates the deadhead pressure against an external valve during start-up that conventional external-valve configurations impose on the motor, reducing motor load and wear. The integrated solenoid provides leak-through protection, making it appropriate for systems requiring tight oil cutoff at the nozzle. It operates across a wide voltage range, accepting 24 volts, 110 to 120 volts AC, and 200 to 240 volts AC at 50 or 60 Hz, as well as 12 volts DC, giving it flexibility across different burner control configurations.

Key Features

• Integrated solenoid valve cuts oil flow almost instantly on shutdown, preventing soot-forming coasting stops
• Delivers up to 4 gallons per hour at 100 psi nozzle pressure
• Rated for hydraulic nozzle pressures from 100 to 200 psi
• Accepts 24V, 110-120V AC, 200-240V AC at 50/60 Hz, and 12V DC voltage inputs
• Fewer moving parts and fewer oil fittings compared to conventional pump designs
• UL and CUL listed; without PD timer

Compatibility

Designed as an OEM-style replacement single-stage oil pump for oil-fired burner systems requiring a solenoid-equipped Clean Cut pump configuration.

Installation Notes

Installation should be performed by a licensed oil-burner technician or qualified HVAC service professional. Shut off all power to the burner and close the oil supply valve before removing or installing the pump. Follow the burner manufacturer's instructions for nozzle pressure settings and supply line connections; consult NFPA 31 for applicable oil-burner installation standards. Do not operate the pump dry, as this can damage internal seals.

Technical Specifications

• Type: Clean Cut Oil Pump, Single Stage
• Nozzle Pressure Range: 100 to 200 psi
• Flow Rate: Up to 4 gallons per hour at 100 psi
• Speed Rating: 3600 RPM
• Voltage Rating: 24V, 110 to 120V AC / 200 to 240V AC at 50/60 Hz, 12V DC
• Power Consumption: 9 watts
• Inlet Pressure Rating: 10 psi
• Return Pressure Rating: 10 psi
• Breakaway Torque: 36 oz-in
• Ambient Temperature Range: 46 to 115 degrees F
• Approvals: UL, CUL
• PD Timer: Not included

Standard Information

• Brand: RW BECKETT
• Manufacturer Part Number: pf20322u
