Rw Beckett 752804 Dpdt Relay 120V Oil Burner

Product Description

The RW BECKETT 752804 is a double-pole double-throw (DPDT) relay rated for 120 volts, designed for use in oil burner control applications. This relay switches load circuits based on control signals from the burner management system, enabling sequenced operation of burner components. It is a direct OEM-specified part for Beckett commercial oil burner units. Licensed oil burner technicians and HVAC service professionals install and replace this component during routine maintenance or control system troubleshooting. The T92P11A22-120 is the Potter Brumfield relay cross-reference associated with this part, which assists in identifying equivalent specifications during sourcing.

This relay is used in Beckett commercial oil burner models including the CF1000, CF1400, CF2300, CF2500, and CF3500. These are commercial-grade forced-draft oil burners commonly found in larger heating systems, boilers, and process heating equipment. Replacement is typically required when the relay fails to pull in, chatters under load, or shows contact wear that causes intermittent burner operation. This part restores proper switching function within the burner control circuit.

Key Features

• Double-pole double-throw (DPDT) contact configuration for versatile switching in burner control circuits
• Rated for 120-volt coil operation, matching standard line-voltage burner control systems
• OEM-specified replacement part for multiple Beckett CF-series commercial oil burners
• Cross-references to Potter Brumfield T92P11A22-120 for specification verification
• Supports reliable sequencing of burner components in commercial heating applications

Compatibility

Confirmed for use in Beckett CF1000, CF1400, CF2300, CF2500, and CF3500 commercial oil burners.

Installation Notes

Installation should be performed by a licensed oil burner technician or qualified HVAC service professional. De-energize and lock out the burner control panel before removing or installing any relay. Verify that the replacement relay coil voltage and contact ratings match the original before energizing the system. Consult the burner wiring diagram to confirm correct terminal connections prior to restoring power.

Technical Specifications

• Coil Voltage: 120 volts
• Contact Configuration: DPDT (Double-Pole Double-Throw)
• Cross-Reference: Potter Brumfield T92P11A22-120

Standard Information

• Brand: RW BECKETT
• Manufacturer Part Number: 752804
