Ruud W951T0703A17M4SNAS 95+ M4 Gas Furnace 3 Ton

Product Description

The RUUD W951T0703A17M4SNAS 95+ M4 Gas Furnace offers dependable heating with a 95% AFUE rating. Features a constant torque single-stage motor and is designed for multi-position installation. The furnace includes a direct spark ignition system and a patented block drain sensor for enhanced safety and reliability. Ideal for residential use, ensuring efficient and consistent performance.

• Features 95% AFUE rating for energy efficiency.
• Equipped with a direct spark ignition (DSI) system for reliability.
• Includes a patented block drain sensor to prevent water damage.

Product Highlights

Efficient and dependable gas furnace with safety features and easy service diagnostics.

Product Information

Standard Information

• Brand: RUUD
• Manufacturer Part Number: W951T0703A17M4SNAS

Technical Specifications

• AFUE: 95%
• Configuration: Multi-Position
• EcoNet Enabled: No
• Motor Type: ECM
• Nominal Size: 3 Ton
• Width: 17.5"
• BTU/HR: 70K
• HEATING CAPACITY BTU/HR: 66,500
• Tonnage: 3
• Application: Gas Furnace 1-Stage
• Communication: Non-Communicating
• Fuel Type: Natural Gas
• BTU Input: 70000
• BTU Output: 66500
• Annual Fuel Usage Efficiency (AFUE): 95.0
• Nominal Cooling Capacity (Tons): 3
• Vent Type: Direct Vent
• Height (inches): 34
• Width (inches): 17.50
• Depth (inches): 29.625
• Weight (pounds): 132
• Building Type: Residential
• Flue Size: 3
• Heating Fan Speed: Medium
• Cooling Fan Speed: High
