Ruud UA16AY36AJ2NA R454B Condenser 3 Ton

Product Description

The Ruud UA16AY36AJ2NA is a three-ton condenser unit suited for residential HVAC applications. This unit is built to run efficiently with a 16+ SEER2 rating and uses R454B refrigerant. Key design features include a two-stage scroll compressor and advanced fan technology, which work together to provide quieter operation. Maintenance is simplified thanks to the PlusOne service access, allowing for easier servicing, and the refrigerant detection system enhances safety.

• Uses R454B refrigerant, which has a lower global warming potential.
• Two-stage scroll compressor delivers efficient cooling performance.
• Features a swept wing fan that reduces sound levels during operation.

Product Highlights

The unit is designed with a focus on energy efficiency, low emissions, and ease of maintenance.

Product Information

Standard Information

• Application: Outdoor Condenser
• Refrigerant Type: R454B

Technical Specifications

• Tonnage: 3
• Voltage: 208/230-1-60
• Compressor Type: 2-Stage Scroll
• Capacity (BTU/HR): 36,000
• Dimensions (LxWxH): 33.75 x 33.75 x 31 inches
• Weight: 208 pounds
• Decibel Level: 72 dB
• Parts Warranty: 10 years
• Compressor Warranty: 10 years
