Ruud rxbh-24a20j-b Electric Heat Kit 20kw 208-240V

Product Description

The RUUD rxbh-24a20j-b is an electric heat kit designed for forced-air air handler systems operating on single-phase power. Rated at 20 kW and compatible with 208-240 volt, 60 Hz electrical supply, this kit adds resistance heating capacity to a matched air handler. It includes a Smart Plug connection for simplified, tool-free installation into compatible RUUD and Rheem SEER2 air handler cabinets. Licensed HVAC technicians install this kit as part of a complete comfort system where supplemental or primary electric heat is required.

This heat kit is engineered to fit new SEER2 air handler equipment. It can also be installed on older SEER-rated air handlers using adapter 251E200, sold separately. Typical applications include residential forced-air systems where a heat pump or cooling-only unit requires an electric heat strip for backup or primary heating. The Smart Plug interface reduces field wiring time and supports correct electrical connections at the unit junction.

Key Features

• 20 kW electric heat output for residential air handler applications
• Operates on 208-240 volt, single-phase, 60 Hz power supply
• Smart Plug connection for simplified installation in SEER2 air handlers
• Compatible with older SEER air handlers using adapter 251E200
• Drop-in kit design for direct installation into the air handler cabinet

Compatibility

Designed for new SEER2 RUUD air handler equipment. Compatible with older SEER air handlers when used with adapter 251E200. Confirm air handler cabinet size and electrical capacity before ordering.

Installation Notes

Installation must be performed by a licensed HVAC technician in accordance with NEC requirements and local electrical codes. Disconnect and lock out all power to the air handler before installing or servicing the heat kit. Verify that the branch circuit ampacity and overcurrent protection match the kit's rated load before energizing. Do not install this kit in an air handler that is not rated to accept an electric heat section.

Technical Specifications

• Heating Capacity: 20 kW
• Voltage: 208-240 volts
• Phase: Single phase
• Frequency: 60 Hz
• Connection Type: Smart Plug

Standard Information

• Brand: RUUD
• Manufacturer Part Number: rxbh-24a20j-b
