Ruud RCF2421MEAMCA Cased Coil 2 Ton

Product Description

The RUUD RCF2421MEAMCA is a 2 ton cased coil designed for use with RUUD outdoor units. Constructed with aluminum fins bonded to internally grooved aluminum tubing and factory-tested for refrigerant leaks. Features copper sweat refrigerant connections and two 3/4" NPT condensate drain connections. Compatible with germicidal light systems.

• Aluminum N-Coils for EcoNet Enabled EEV Metering
• Factory-tested with an extensive refrigerant leak check
• Bi-directional airflow eliminates switching internal components

Product Highlights

The RCF2421MEAMCA coil features a unique drain pan design, maximizing application flexibility and condensate removal. AHRI Certified and cULus Listed.

Product Information

Standard Information

• Brand: RUUD
• Manufacturer Part Number: RCF2421MEAMCA

Technical Specifications

• Application: Multi-Poise
• Cased-Uncased: Cased
• Liquid Line Size: 3/8"
• Material: Aluminum/Aluminum
• Nominal BTUH Cool: 24000
• Refrigerant: R-410A
• Style: N-Coil
• Suction Line Size: 3/4"
• Tons: 2
• Brand: RUUD
• Type: Cooling
• Nominal Capacity (Tons): 2
• Configuration: Multiposition
• Inlet Size: 3/8
• Outlet Size: 3/4
• Rows: 2
• Cased: Yes
• Depth (inches): 21.6875
• Height (inches): 20.5
• Width (inches): 21
