Ruud RA15AY60AJ1NA Endeavor Line Achiever Series Air Conditioner 60000 Btu/h

Product Description

The Ruud RA15AY60AJ1NA Endeavor Line Achiever Series Air Conditioner is a single-stage, five-ton unit designed for cooling efficiency. With a SEER2 rating of 15.2, it operates effectively on 208 to 230 volts and uses R-454B refrigerant. This model features a seven-millimeter condenser copper coil, which minimizes refrigerant needs and enhances overall reliability.

• Incorporates PlusOne expanded valve space for simplified servicing.
• Offers PlusOne triple service access for quick repairs.
• Uses swept wing fan technology for quieter performance.

Product Highlights

This air conditioner is ideal for residential or light commercial applications, providing efficient cooling with a focus on ease of maintenance.

Product Information

Standard Information

• Brand: Ruud
• Type: Air Conditioning

Technical Specifications

• Nominal Capacity: 60000 Btu/h
• Refrigerant Type: R-454B
• Compressor Type: Scroll
• Sound Level: 76 dB
• Voltage: 208 to 230 V
• Number of Phases: 1
• Maximum Overcurrent Protection: 50 A
• Minimum Circuit Ampacity: 31 A
• Compressor - Rated Load Amps: 24 A
• Condenser Fan Motor - Full Load Amps: 1.00 A
• Outdoor Fan Diameter: 26 in
• Motor HP: 1/5 hp
• CFM: 4169 ft³/min
• Total Capacity: 56000 Btu/h
• SEER2: 13.8
• Indoor CFM: 1575 ft³/min
• Dimensions: 35.75 x 35.75 x 45.00 inches
• Parts Warranty: 10 years (if registered)
• UPC: 633190083180
