Ruud PD540043 Filter Media Merv 8 21x28x5 in UXGF-E21M13

Product Description

The RUUD PD540043 is a MERV 8 replacement filter media cartridge designed for use in RUUD and compatible media air cleaners. Measuring 21 inches by 28 inches by 5 inches, this media filter features finger-supported vertical pleats that stay evenly spaced under airflow, maximizing dirt-holding capacity while keeping static pressure drop low. A factory-installed double gasket runs along the top and bottom edges to eliminate filter bypass, ensuring all air passes through the media. The moisture-resistant frame maintains structural integrity even in high-humidity environments, making it suitable for a wide range of forced-air HVAC installations. HVAC technicians install this unit as a direct replacement during routine maintenance.

This filter media is engineered as a custom-sized replacement for XHF and XGF series media air cleaners. It is suitable for use with all types of forced-air HVAC configurations, including residential and light-commercial systems. The galvanized, rust-resistant wire mesh integral to the filter provides structural support for the media and retains pleat shape throughout the service life of the filter, including when the media is heavily loaded with particulate. The UXGF-E21M13 media air cleaner is a confirmed compatible unit.

Key Features

• MERV 8 filtration rating for effective capture of common airborne particulates
• Finger-supported vertical pleats maintain even spacing and maximize dirt-holding capacity at low pressure drop
• Factory-installed double gasket on top and bottom eliminates filter bypass
• Moisture-resistant frame retains strength and shape in high-humidity conditions
• Galvanized, rust-resistant wire mesh supports media and holds pleat shape even when filter is dirty
• UL900 listed

Compatibility

Designed as a custom-sized replacement for XHF and XGF series media air cleaners, including the UXGF-E21M13. Suitable for use with all types of forced-air HVAC configurations.

Installation Notes

Installation should be performed by a licensed HVAC technician. Power down the air handler or furnace at the disconnect or breaker before accessing the media air cleaner cabinet. Confirm the replacement media is oriented with the airflow arrow matching the direction of system airflow. Inspect the gasket seating after insertion to verify a full perimeter seal before returning the system to service.

Technical Specifications

• MERV Rating: 8
• Filter Dimensions: 21 inches x 28 inches x 5 inches
• Frame Material: Moisture-resistant
• Wire Mesh: Galvanized, rust-resistant
• Gasket: Double gasket, factory installed, top and bottom
• Certification: UL900

Standard Information

• Brand: RUUD
• Manufacturer Part Number: PD540043
