Ruud 62-25341-81 Integrated Furnace Control Board

Product Description

The RUUD 62-25341-81 is an integrated furnace control board designed for use in RGDG series gas furnaces. This board manages ignition sequencing, inducer and blower motor operation, limit and pressure switch monitoring, and fault diagnostics within the furnace control circuit. At 8.1 inches in length and 6.1 inches in width, it is a direct-fit replacement for the original control module. Weighing 0.8 pounds, it is a manageable component for bench testing or in-unit installation. Licensed HVAC technicians performing scheduled maintenance or responding to no-heat calls will typically handle this replacement.

This control board is used in RGDG series residential gas furnaces. It is suited for applications where the original integrated control board has failed, is displaying fault codes, or has sustained damage from electrical surges or moisture. The board integrates multiple control functions into a single PCB, reducing the number of discrete components a technician needs to diagnose or replace during a service call.

Key Features

• Integrated design consolidates ignition control, blower sequencing, and fault diagnostics on one board
• Direct-fit replacement form factor at 8.1 x 6.1 x 2.15 inches
• Lightweight at 0.8 pounds for easier handling during installation
• Designed for RGDG series gas furnace platforms
• OEM-specified part number ensures proper firmware and relay configuration for the application

Compatibility

Designed as an OEM replacement integrated furnace control board for RUUD RGDG series gas furnaces.

Installation Notes

Installation should be performed by a licensed HVAC technician in accordance with applicable local codes and the furnace manufacturer service documentation. Disconnect power to the furnace at the disconnect switch and confirm the circuit is de-energized before removing the existing control board. Document or photograph all wiring connections prior to removal to ensure correct reassembly. After installation, cycle the furnace through a complete startup sequence and verify proper operation and absence of fault codes.

Technical Specifications

• Type: Integrated Furnace Control Board
• Length: 8.1 inches
• Width: 6.1 inches
• Height: 2.15 inches
• Weight: 0.8 pounds

Standard Information

• Brand: RUUD
• Manufacturer Part Number: 62-25341-81
