RUUD 51-42537-01 Blower Motor Power 3 Horsepower

Product Description

The RUUD 51-42537-01 is a three-phase blower motor suitable for both direct and belt drive applications. This motor operates efficiently on input voltages of 208 to 230, 380 to 415, and 460 VAC. It delivers a power output of three horsepower and features a speed of 1725 RPM with reversible rotation.

• Operates on multiple voltage inputs: 208 to 230/380 to 415/460 VAC
• Reversible rotation at a speed of 1725 RPM
• Designed for robust platform mounting

Product Highlights

This blower motor supports both 50 Hz and 60 Hz frequencies, making it versatile for multiple systems. The motor has a 56HZ frame and features ball bearings for smooth operation. The shaft is 7/8 inch in diameter and 2-1/4 inches in length, suitable for various applications.

Product Information

Standard Information

• Brand: RUUD
• MPN: 51-42537-01

Technical Specifications

• Input Voltage: 208 to 230/380 to 415/460 VAC
• Full Load Amperage: 9.2/4.6 A
• Horsepower: 3 hp
• Speed: 1725 rpm
• Phase: 3 ph
• Frequency: 50 Hz, 60 Hz
• Frame Size: 56HZ
• Shaft Diameter: 7/8 in
• Shaft Length: 2-1/4 in
• Rotation: Reversible
• Number of Speeds: 1
• Bearing Type: Ball
• Mounting Type: Platform
• Drive Type: Direct Drive
• Motor Application: Belt Drive Blower
• Locked Rotor Amperage at 230V: 74.5 A
• Locked Rotor Amperage at 460V: 38.1 A
• Motor Body Diameter: 6-1/2 in
• Keyed/Flat Shaft Length: 1-3/4 in
• Motor Body Length: 11-1/16 in
• Overall Motor Length: 13-5/16 in
