RUUD 51-42368-02 Blower Motor 1 HP 208/230/460 VAC Replacement MPN

Product Description

The RUUD 51-42368-02 is a blower motor suitable for various applications. It operates within a voltage range from 208 to 230/460 VAC and has a power rating of 1 horsepower. This motor features a single speed of 1725 RPM, making it efficient for many blower tasks. It is designed for platform mounting and includes reversible rotation capabilities to suit different installation needs.

• Operates at 1725 RPM with a single speed.
• Features reversible rotation and belt drive.
• Designed for platform mounting.

Product Highlights

This blower motor is built for reliability, utilizing a belt drive system and incorporating ball bearings for smooth operation.

Product Information

Standard Information

• Brand: RUUD
• MPN: 51-42368-02

Technical Specifications

• Application: Blower
• Bearing Type: Ball
• Drive Type: Belt Drive
• FLA at 230V (A): 2.80
• FLA at 460V (A): 1.40
• Frame Size: 56
• Frequency (Hz): 60
• Speed Rating: 1725 RPM
• HP Rating: 1 HP
• Input Voltage (V): 208 | 230 | 380-415 | 460
• Keyed/Flat Shaft Length (in): 3/16 x 3/16 x 1-3/4
• LRA at 230V (A): 17.40
• LRA at 460V (A): 8.70
• Motor Body Diameter (in): 6-1/2
• Motor Body Length (in): 10-1/16
• Mounting Type: Platform
• Number of Phases: 3
• Number of Speeds: 1
• Overall Motor Length (in): 12-3/8
• Overall Shaft Length (in): 2-1/4
• Rotation Type: Reversible
• Shaft Diameter (in): 5/8
• Motor Enclosure Type: Open Drip-Proof
• Dimensions: 6-1/2 in Diameter x 12-3/8 in Length
