Ruud 51-23053-21 Rheem Protech TripSaver Condenser Fan Motor 1/6 HP to 1/3 HP 208-230V 1-Phase 60Hz 1075 RPM 2-Speed

Product Description

The RUUD 51-23053-21 Rheem Protech TripSaver Condenser Fan Motor operates at 1/6 HP to 1/3 HP with 208-230V, 1-Phase, and 60Hz. It features a high speed of 1075 RPM and a low speed of 900 RPM. The motor has a reversible rotation and a 1/2 inch shaft diameter. Run capacitor not included: 5/370 (230V), 7.5/370 (208V).

• Run capacitor not included: 5/370 (230V), 7.5/370 (208V)
• Genuine Factory OEM repair part
• 1/6-1/3HP, 208-230Vac, Single Phase, 1075/900 RPM, 2 Speed, 2.6 Amps, 48 Nema Frame Size, Totally Enclosed Enclosure, Sleeve Bearing, Shell-Band/Shell-Screw/Thru-Bolt Mount, 1/2" x 3 3/4" Shaft, Reversible Rotation, Permanent Split Capacitor Motor

Product Highlights

This condenser fan motor is designed for direct drive applications and features a reversible rotation.

Product Information

Standard Information

• Brand: RUUD
• Manufacturer Part Number: 51-23053-21

Technical Specifications

• Speed: 1075 RPM
• Voltage: 208-230Vac
• Horsepower: 1/6-1/3HP
• Phase: Single Phase
• RPM: 1075/900 RPM
• Amps: 2.6 Amps
• Frame Size: 48 Nema Frame Size
• Enclosure: Totally Enclosed Enclosure
• Bearing Type: Sleeve Bearing
• Mounting: Shell-Band/Shell-Screw/Thru-Bolt Mount
• Shaft Size: 1/2" x 3 3/4"
• Rotation: Reversible Rotation
• Motor Type: Permanent Split Capacitor Motor
• Drive Type: Direct
• Speeds: 2
• Application: Condenser
