RUUD 51-21853-11 RUUD Condenser Fan Motor 1/3 HP (Various) Replacement MPN

Product Description

The RUUD 51-21853-11 is a condenser fan motor suitable for air conditioning split systems and furnace applications. This motor operates on voltages of 208-230V or 460V and at a frequency of sixty Hertz. It has a power rating of one-third horsepower and runs at a speed of 1075 RPM with a single operational speed. The design features counter-clockwise rotation and a shell screw mount for secure installation, making it fit for direct drive applications.

• Condenser fan motor with 1/3 HP power.
• Operates at 1075 RPM with a single speed.
• Designed for condenser and furnace applications.

Product Highlights

This motor is essential for efficient heating and cooling solutions within HVAC systems, ensuring durability and reliability in operation.

Product Information

Standard Information

• Brand: RUUD
• MPN: 51-21853-11

Technical Specifications

• Compatible Product: Air Conditioner Split System
• Power Phase: 1 Phase
• Type: Furnace Motor
• Power: 1/3 hp
• Rotation: Counter-Clockwise
• RPM: 1075
• Voltage: 208V | 230V
• Mounting Type: Shell Screw
• Frequency Rating: 60 Hz
• Input Voltage: 208 | 230
• Shaft Size: 1/2 in Dia
• Shaft Length: 1-3/4 in
• Overall Motor Length: 6-1/2 in
• Shaft Diameter: 1/2 in
• FLA at 208V: 1.50 A
