Trane M5THS2324A11NA Split System Heat Pump 24000 Btu R-454B Refrigerant

Product Description

The Trane M5THS2324A11NA is a residential split system heat pump outdoor unit designed for whole-home cooling and heating applications. Operating on R-454B refrigerant, this unit reflects Trane's shift toward lower global-warming-potential refrigerant technology in compliance with current environmental standards. Rated at approximately 24,000 BTU, it is sized for a 2-ton application and is intended for installation by a licensed HVAC technician as part of a matched split system. The M5THS2324A11NA is built for standard residential pad or slab mounting and connects to a compatible indoor air handler or coil to complete the system.

This unit is suited for residential single-family and light multi-family installations where a 2-ton cooling and heating capacity meets the load requirement. It is designed for use in split system configurations where the outdoor condensing section is paired with an indoor evaporator coil or air handler. Typical installations involve replacement of an aging outdoor unit or as part of a new system build-out in residential construction. Licensed HVAC contractors performing equipment changeouts or new installs are the primary installers of this unit.

Key Features

• R-454B refrigerant — lower global-warming-potential alternative to legacy refrigerants
• 24,000 BTU (2-ton) capacity for residential split system applications
• Outdoor condensing unit designed for slab or pad installation
• Part of Trane's current-generation residential split system lineup
• Designed for matched pairing with a compatible indoor coil or air handler

Compatibility

Designed as an OEM residential split system outdoor unit intended for use with a compatible Trane matched indoor coil or air handler. Consult Trane's current matchup guide to confirm indoor unit compatibility before installation.

Installation Notes

Installation must be performed by a licensed HVAC technician holding an EPA Section 608 certification, as R-454B is a regulated refrigerant requiring certified handling. Disconnect and lock out all electrical power to the system before making any refrigerant or electrical connections. The unit should be mounted on a level concrete pad or approved equipment base per manufacturer guidelines and local mechanical codes. Do not operate the system without verifying proper refrigerant charge and system static pressures using calibrated gauges.

Technical Specifications

• Refrigerant Type: R-454B
• Cooling Capacity: 24,000 BTU
• Shipping Height: 19.09 inches
• Shipping Length/Depth: 40.47 inches

Standard Information

• Brand: Trane
• Manufacturer Part Number: M5THS2324A11NA
