Trane A801X100CM5SC Gas Furnace 100000 Btu/h 80% Afue Single Stage Multi-position

Product Description

The Trane A801X100CM5SC is a single-stage, induced draft gas furnace rated at 100,000 BTU/h input and 80% AFUE. It is designed for multi-position installation, supporting upflow, downflow, horizontal left, and horizontal right configurations. The unit runs on a 120/1/60 power supply with 24-volt control and uses a high efficiency motor to move conditioned air through residential duct systems. An integrated furnace control board handles setup, status, and diagnostics with a digital display and stores the last six fault codes for quick troubleshooting. Licensed HVAC technicians install and service this unit.

This furnace is suited for residential forced-air heating applications where installation space, orientation requirements, or load demands vary by job. The 21-inch cabinet width follows industry standard dimensions, and the approximately 28.75-inch depth is compatible with industry standard evaporator coils and accessories. The open vestibule design stands 34 inches high, giving technicians clear access to components during installation and service. The cabinet meets ASHRAE 193 air leakage requirements at 1.4% or less, supporting system efficiency at the rated AFUE.

Key Features

• 100,000 BTU/h input capacity with 80% AFUE single-stage operation
• Four-way multi-position installation: upflow, downflow, horizontal left, horizontal right
• High efficiency inducer motor with variable speed draft control
• Integrated furnace control with digital display, diagnostic codes, and last six error log
• All Molex connections on control board — no spade terminals
• Industry standard 21-inch cabinet width compatible with standard coils and accessories
• Air-tight cabinet at 1.4% or less leakage per ASHRAE 193

Compatibility

Designed as a multi-position residential gas furnace compatible with industry standard evaporator coils and duct accessories. The 21-inch cabinet width and approximately 28.75-inch depth conform to industry standard footprints. Operates with 24-volt thermostat control wiring.

Installation Notes

Installation must be performed by a licensed HVAC technician in accordance with local codes and the applicable provisions of the International Fuel Gas Code. Shut off gas supply and disconnect electrical power before servicing or making any connections. Verify the installation orientation — upflow, downflow, or horizontal — matches the configured drain and venting arrangement before startup. Follow the manufacturer installation, operation, and maintenance manual for all clearance, venting, and commissioning requirements.

Technical Specifications

• Input Capacity: 100,000 BTU/h
• AFUE: 80%
• Stages: Single stage
• Power Supply: 120/1/60 (120 volts, single phase, 60 Hz)
• Control Voltage: 24 volts
• Cabinet Width: 21 inches
• Cabinet Depth: 28.75 inches
• Vestibule Height: 34 inches (open)
• Air Leakage: 1.4% or less per ASHRAE 193
• Unit Weight: 136 pounds
• Installation Positions: Upflow, Downflow, Horizontal Left, Horizontal Right

Standard Information

• Brand: Trane
• Manufacturer Part Number: A801X100CM5SC
