Trane A801X080BM4SC 80 Percent Afue Gas Furnace 80000 Btu Multipositional Upflow Downflow Horizontal

Product Description

The Trane A801X080BM4SC is a single-stage, multipositional gas furnace rated at 80,000 BTU input capacity and 80 percent AFUE efficiency. It is designed for residential forced-air heating systems and can be installed in upflow, downflow, or horizontal left/right orientations, making it adaptable to a wide range of installation layouts. The furnace operates on 120/1/60 voltage with 24-volt low-voltage control and features an integrated furnace control board with digital display, setup and diagnostic functions, and storage of the last six fault codes. All electrical connections use Molex connectors. A four-speed direct-drive blower motor handles airflow for both heating and cooling modes. Licensed HVAC technicians perform installation and service.

The A801X080BM4SC is suited for residential applications where a single-stage, non-condensing gas furnace is specified. Its multipositional cabinet design accommodates upflow, downflow, and horizontal installations, giving installers flexibility in equipment room, closet, attic, and crawlspace placements. The open vestibule design provides a full 34-inch high access area for ease of service. The cabinet width of 17.5 inches is compatible with industry-standard evaporator coils and accessories, making it a practical choice for split-system configurations where a matched or compatible cooling coil is installed above or below the unit.

Key Features

• 80,000 BTU input capacity with 80 percent AFUE single-stage heating
• Multipositional installation: upflow, downflow, horizontal left, and horizontal right
• Integrated furnace control board with digital display and last-six-error fault memory
• Four-speed direct-drive blower motor rated at 1,600 CFM, suitable for up to 4-ton cooling
• All Molex electrical connections — no spade terminals
• Air-tight cabinet with 1.4 percent or less air leakage per ASHRAE 193
• Open vestibule design with 34-inch clearance height for accessible service

Compatibility

The A801X080BM4SC has a 17.5-inch wide cabinet compatible with industry-standard evaporator coils and accessories. It has been listed as a component in 2.5-ton split-system configurations paired with matched cooling equipment. Confirm coil and system compatibility with Trane or RunTru selection guides before installation.

Installation Notes

Installation must be performed by a licensed HVAC technician in accordance with local mechanical codes, the National Fuel Gas Code (NFPA 54/ANSI Z223.1), and the manufacturer's installation, operation, and maintenance manual. Shut off gas supply and disconnect electrical power before beginning any service or installation work. Vent this furnace using approved non-condensing vent materials sized per the venting tables in the installation guide; do not use PVC for flue venting on this 80 percent AFUE unit. Verify proper gas line sizing, combustion air supply, and condensate drainage provisions before startup.

Technical Specifications

• Input Capacity: 80,000 BTU/h
• AFUE: 80 percent
• Stages: 1
• Blower CFM Rating: 1,600 CFM
• Blower Size: 11 x 8 inches
• Blower Motor Speed: 1,075 RPM
• Motor Power: 3/4 HP
• Voltage: 120 volts AC, 60 Hz, 1-Phase
• Control Voltage: 24 volts
• Amperage Rating: 13.06 amps
• Cabinet Height: 34 inches
• Cabinet Width: 17.5 inches
• Cabinet Depth: 28.75 inches
• Installation Positions: Upflow, Downflow, Horizontal Left, Horizontal Right
• Air Leakage: 1.4 percent or less per ASHRAE 193

Standard Information

• Brand: Trane
• Manufacturer Part Number: A801X080BM4SC
