Trane A801X060BM4TC Single Stage Gas Furnace 80000 Btu/h Upflow Horizontal

Product Description

The Trane A801X060BM4TC is an 80% AFUE single-stage induced draft gas furnace designed for upflow and horizontal installations in residential forced-air heating systems. Operating at a nominal heating input of 80,000 BTU/h, this unit falls within Trane's 80% induced draft furnace lineup and features a cabinet width of 17.5 inches. It is built for installation by licensed HVAC technicians in central ducted systems where consistent, single-stage heat delivery is the primary requirement. The 9-speed constant torque blower motor provides adequate airflow for both heating and cooling modes, switching speeds automatically between the two operating modes.

This furnace is suited for residential applications requiring upflow or horizontal airflow configuration. The 17.5-inch cabinet width fits standard air handler closets and utility room installations. The constant torque blower motor allows this unit to support combined heating and cooling system installations, making it a practical choice for split system setups where the furnace serves as the indoor air handler for an associated cooling coil. Installation in new construction or replacement applications is common for this product type.

Key Features

• 80% AFUE single-stage induced draft operation for reliable heating performance
• Nominal heating input of 80,000 BTU/h suits medium-sized residential spaces
• 9-speed constant torque blower motor transitions between heating and cooling airflow speeds automatically
• 17.5-inch cabinet width fits standard closet and alcove installations
• Upflow and horizontal airflow configurations supported in a single unit

Compatibility

Designed as an OEM-style upflow and horizontal single-stage gas furnace replacement within Trane's 80% induced draft furnace product line. Consult Trane system documentation to confirm compatibility with specific air conditioning coils, thermostats, and venting configurations before installation.

Installation Notes

Installation must be performed by a licensed HVAC technician in accordance with local mechanical codes and the manufacturer's installation instructions. Shut off gas supply and disconnect electrical power before beginning any service or replacement work. Venting must be configured to meet local code requirements for 80% induced draft appliances, typically using Type B vent or equivalent approved materials. Do not operate the unit before verifying all gas connections, flue connections, and electrical wiring are complete and inspected.

Technical Specifications

• AFUE: 80%
• Heating Input: 80,000 BTU/h
• Number of Heating Stages: Single Stage
• Blower Motor Type: 9-Speed Constant Torque
• Cabinet Width: 17.5 inches
• Airflow Configuration: Upflow and Horizontal
• Draft Type: Induced Draft

Standard Information

• Brand: Trane
• Manufacturer Part Number: A801X060BM4TC
