Trane A801X040BM2SC Single Stage 80 Percent Afue Gas Furnace 40000 Btu/h 17.5 Inch Cabinet Upflow Horizontal

Product Description

The Trane A801X040BM2SC is a single-stage, 80% AFUE induced-draft gas furnace designed for residential heating applications. It delivers 40,000 BTU/h of heating input capacity and operates on a 24-volt control circuit with 120/1/60 power supply. The cabinet is 17.5 inches wide, making it suitable for installations where space is a consideration. This furnace supports four-way convertible airflow, allowing upflow or horizontal left and right configurations. Licensed HVAC technicians install and commission this unit as part of a split or packaged heating system.

This furnace is intended for residential installations where single-stage heating and 80% AFUE efficiency meet local code requirements. The four-way airflow flexibility accommodates a range of duct configurations, including upflow and horizontal orientations, fitting both new construction and replacement scenarios. At 40,000 BTU/h input, it is sized for smaller to mid-size residential conditioned spaces. The unit uses a conventional thermostat-compatible 24-volt control system, integrating with standard low-voltage wiring setups common in residential HVAC systems.

Key Features

• Single-stage heating operation at 40,000 BTU/h input capacity
• 80% AFUE efficiency rating meets standard residential efficiency requirements
• Four-way convertible airflow supports upflow and horizontal left or right installation
• 17.5-inch cabinet width for installations with moderate space constraints
• 24-volt control circuit compatible with standard residential thermostat wiring
• 120/1/60 power supply for standard single-phase residential electrical connections

Compatibility

Designed as an OEM-style replacement or new-installation furnace for residential gas heating systems requiring a single-stage, 80% AFUE, 40,000 BTU/h unit with a 17.5-inch cabinet width and four-way convertible airflow.

Installation Notes

Installation must be performed by a licensed HVAC technician in accordance with local mechanical codes and the International Fuel Gas Code (IFGC). Shut off gas supply and disconnect electrical power before beginning any service or replacement work. Verify that the duct system, flue venting, and gas line sizing are appropriate for the unit before commissioning. Do not attempt to modify airflow configuration after installation without consulting applicable installation documentation.

Technical Specifications

• Heating Input Capacity: 40,000 BTU/h
• AFUE Rating: 80%
• Number of Heating Stages: 1
• Airflow Configuration: 4-way convertible (upflow and horizontal)
• Control Voltage: 24 volts
• Power Supply: 120/1/60
• Cabinet Width: 17.5 inches
• Cabinet Depth: 28.75 inches

Standard Information

• Brand: Trane
• Manufacturer Part Number: A801X040BM2SC
