Trane A5PG3048A1090A Single Packaged Gas Electric Unit 47500 Btu/h 5 Ton 208-230V R-454B

Product Description

The Trane A5PG3048A1090A is a single packaged gas heating and electric cooling unit designed for rooftop or ground-level installation in residential and light commercial applications. Operating on R-454B refrigerant, it delivers 47,500 BTU/h of cooling capacity with a rated power input of 4.3 kilowatts and achieves an EER2 of 10.6 and a SEER2 of 13.40. On the heating side, it fires at 90,000 BTU/h first-stage natural gas input with an AFUE of 81. Rated for 208-230 volt, single-phase, 60 Hz service, this unit is installed by licensed HVAC technicians as a complete, self-contained heating and cooling solution requiring no separate indoor air handler or furnace.

The A5PG3048A1090A is suited for single-zone residential and light commercial buildings where a rooftop or slab-mounted packaged system is preferred over a split system. Indoor airflow is rated at 1,670 CFM, supporting duct systems designed for 5-ton nominal capacity. The unit uses the low-GWP R-454B refrigerant, aligning with current regulatory requirements for new equipment. It is part of the Trane A5PG3048 product family, which covers the 5-ton convertible entry packaged gas-electric line.

Key Features

• 47,500 BTU/h cooling output with 13.40 SEER2 efficiency rating
• 90,000 BTU/h first-stage natural gas heating input at 81 AFUE
• R-454B refrigerant — low global warming potential, current-regulation compliant
• Single-phase 208-230 volt, 60 Hz electrical configuration
• 1,670 CFM rated indoor airflow for 5-ton duct systems
• 72.5 dB(A) sound power rating for a packaged rooftop unit

Compatibility

The A5PG3048A1090A belongs to the Trane A5PG3048 single packaged gas-electric family. It is designed as a complete rooftop or ground-mounted packaged unit and connects directly to an existing duct system without a separate indoor coil or air handler. Verify electrical supply, gas line sizing, and duct static pressure against the published submittal data before installation.

Installation Notes

Installation must be performed by a licensed HVAC technician in accordance with local mechanical codes, the current edition of the IFGC, and applicable electrical codes including the NEC. Disconnect and lock out all electrical power and close the gas supply valve before servicing the unit. Follow the manufacturer installation and operations manual for refrigerant charging procedures, as the unit uses R-454B and must be charged to the nameplate weight specification. Ductwork connections, curb mounting, and condensate drainage must be confirmed before startup.

Technical Specifications

• Cooling Capacity: 47,500 BTU/h
• Heating Input (1st Stage, Natural Gas): 90,000 BTU/h
• SEER2: 13.40
• EER2: 10.6
• AFUE: 81
• Rated Voltage: 208-230 volts, single-phase, 60 Hz
• Power Input (Cooling): 4.3 kilowatts
• Indoor Airflow: 1,670 CFM
• Sound Power Rating: 72.5 dB(A)
• Refrigerant: R-454B
• Nominal Capacity: 5 ton

Standard Information

• Brand: Trane
• Manufacturer Part Number: A5PG3048A1090A
