Trane A5PA3036A1000 Packaged Air Conditioner with Electric Heat 36000 Btu 3 Ton 13.4 SEER2 R-454B Convertible

Product Description

The Trane A5PA3036A1000 is a single-package cooling and electric heat unit from the RunTru by Trane A5PA3 series, designed for residential and light-commercial rooftop or ground-level installations. This self-contained unit delivers 36,800 BTU/h of cooling capacity at a rated 13.4 SEER2 and 10.6 EER2, with a power input of 3.12 kilowatts. It operates on 208-230 volt, single-phase, 60 Hz power and uses R-454B refrigerant, the current low-GWP replacement for R-22 and R-410A in new equipment. Licensed HVAC technicians handle installation, startup, and refrigerant service on this equipment.

The A5PA3036A1000 is built for convertible airflow configurations, supporting both downflow and horizontal duct arrangements in a single cabinet. This makes it suitable for slab-mounted or rooftop applications where duct orientation varies by job site. The unit is sized at 3 tons for residential structures or small commercial spaces requiring a compact all-in-one solution that combines cooling and electric resistance heat without a separate air handler or furnace. Rated airflow is 1,190 CFM to match standard duct systems in its tonnage class.

Key Features

• 36,800 BTU/h cooling output rated per AHRI Standard 210/240
• 13.4 SEER2 and 10.6 EER2 efficiency ratings for current federal compliance
• R-454B refrigerant — A2L low-GWP, compliant with current refrigerant transition requirements
• Convertible airflow configuration supports downflow and horizontal installations
• Scroll compressor rated at 208-230V/1-phase/60 Hz with 16.7 RLA and 93.5 LRA
• Spine-fin outdoor coil construction, 2-row by 24 FPI configuration
• Sound power rating of 69.3 dB(A) for noise-sensitive install environments

Compatibility

Designed as an OEM-style single-packaged cooling and electric heat unit within the Trane RunTru A5PA3 series, rated for 2- to 5-ton convertible entry-level packaged applications using R-454B refrigerant.

Installation Notes

Installation must be performed by a licensed HVAC technician holding the appropriate EPA Section 608 certification for A2L refrigerant handling. Disconnect and lock out all electrical power before servicing any electrical or refrigerant components. Verify supply voltage matches the 208-230 volt single-phase requirement before energizing. Follow applicable local mechanical codes and manufacturer startup procedures for refrigerant system commissioning and airflow verification.

Technical Specifications

• Cooling Capacity: 36,800 BTU/h
• Tonnage: 3 tons
• SEER2: 13.4
• EER2: 10.6
• Voltage/Phase/Frequency: 208-230V / 1-phase / 60 Hz
• Power Input: 3.12 kilowatts
• Power Connection: 40 amps
• Compressor Type: Scroll
• Compressor RLA / LRA: 16.7 / 93.5 amps
• Refrigerant: R-454B
• Airflow: 1,190 CFM
• Airflow Configuration: Convertible (downflow and horizontal)
• Outdoor Coil Type: Spine-fin, 2 rows / 24 FPI
• Sound Power Rating: 69.3 dB(A)
• Actual Weight: 384 pounds

Standard Information

• Brand: Trane
• Manufacturer Part Number: A5PA3036A1000
