Trane A5HL5048A1000A Side Discharge Split System Heat Pump 4 Ton 48000 Btu R-454B 15.2 SEER2 Residential

Product Description

The Trane A5HL5048A1000A is a 4-ton, side-discharge, split-system heat pump outdoor condenser designed for residential heating and cooling applications. Operating on R-454B refrigerant and rated at 15.2 SEER2, this unit delivers 48,000 BTU/h of nominal capacity at 208/230 volts, single phase, 60 Hz. The aluminum and copper coil construction provides durable heat transfer performance. Low-voltage system control runs at 24 volts, compatible with standard thermostat wiring. Licensed HVAC technicians install and commission this unit as part of a split-system configuration paired with a matching air handler or coil and furnace.

This unit is suited for residential split-system heat pump installations in moderate climates where a 4-ton capacity is appropriate for the structure's load calculation. It is configured for side discharge airflow and is designed to work as the outdoor section of a ducted split system. The A5HL5048A1000A carries a multi-speed designation and is part of the RunTru by Trane product family. Minimum circuit ampacity is 31 amps, and maximum overcurrent protection is 50 amps. Outdoor unit dimensions are 52.40 inches high, 37.40 inches wide, and 13.39 inches deep per submittal data.

Key Features

• 4-ton nominal capacity with 48,000 BTU/h output
• R-454B refrigerant — compliant with current low-GWP refrigerant regulations
• 15.2 SEER2 efficiency rating for residential applications
• Side-discharge configuration for flexible outdoor placement
• Aluminum and copper coil construction for corrosion resistance and heat transfer efficiency
• 24-volt system control interface compatible with standard low-voltage thermostats
• Factory-installed compressor heat and sound blanket insulation per submittal documentation

Compatibility

Designed as an OEM split-system heat pump outdoor condenser for use with a compatible matched indoor air handler or cased coil and, in dual-fuel configurations, a compatible gas furnace. Specific system matchups should be verified against Trane or AHRI certified matched-system ratings prior to installation.

Installation Notes

Installation must be performed by a licensed HVAC technician in accordance with local mechanical codes and the equipment submittal data. Disconnect and lock out all electrical power before servicing the unit. Refrigerant handling and system charging require EPA Section 608 certification. Verify that the electrical supply meets the minimum circuit ampacity and maximum overcurrent protection requirements before energizing the unit.

Technical Specifications

• Nominal Capacity: 4 tons
• Nominal Capacity BTU/h: 48,000 BTU/h
• SEER2: 15.2
• Refrigerant Type: R-454B
• Voltage / Phase / Frequency: 208/230 volts / 1 phase / 60 Hz
• Minimum Circuit Ampacity: 31 amps
• Maximum Overcurrent Protection: 50 amps
• Running Load Amps: 16.5 amps
• System Control Voltage: 24 volts
• Coil Material: Aluminum and copper
• Discharge Direction: Side discharge
• Unit Height: 52.40 inches
• Unit Width: 37.40 inches
• Unit Depth: 13.39 inches
• Compressor Stages: 1 multi-speed
• Factory Installed Compressor Heat: Yes
• Factory Installed Sound Blanket: Yes
• Outdoor Fan Type: Propeller

Standard Information

• Brand: Trane
• Manufacturer Part Number: A5HL5048A1000A
