Rubber r82005001 Red Sbr Gasket Material 1/16 in X 33 Ft

Product Description

The RUBBER r82005001 is a general-purpose red SBR (styrene-butadiene rubber) gasket material supplied on a bulk spool, measuring 1/16 inch thick by 33 feet in length. It is designed for fabricating custom flange gaskets in plumbing, HVAC, and light industrial applications where a flexible, compressible sealing material is required. The SBR compound delivers solid abrasion resistance and handles a maximum service temperature of 160 degrees F. Oil resistance is limited, so this material is best suited for water, low-pressure steam, and similar non-petroleum service. Plumbers, pipefitters, and maintenance technicians commonly work with this type of bulk roll when cutting gaskets to fit non-standard flange dimensions.

This gasket roll is suited for residential and light commercial maintenance work where pre-cut gaskets are unavailable or a custom shape is needed. It is appropriate for use between flanged pipe connections, valve bodies, and equipment access covers in water and HVAC service. The bulk 33-foot spool format allows technicians to cut multiple gaskets from a single roll, reducing material waste and keeping a versatile sealing stock on the service vehicle or shop bench.

Key Features

• General-purpose SBR rubber compound with strong abrasion resistance
• Maximum service temperature of 160 degrees F
• 1/16 inch thickness suitable for standard flange seating applications
• 33-foot bulk spool allows on-site custom gasket cutting
• Limited oil resistance — best used in water and non-petroleum service lines
• Red color aids visual identification during installation and inspection

Compatibility

Designed as a general-purpose gasket material for flanged connections in water, low-pressure steam, and non-petroleum piping systems. No specific equipment or model compatibility is stated by the manufacturer for this material.

Installation Notes

Shut off the system and relieve all line pressure before removing existing gaskets or installing new ones. Cut the gasket material to match the flange face dimensions using a sharp utility knife, gasket cutter, or hole punch set. Ensure mating flange surfaces are clean and free of debris before seating the new gasket. Verify that the service fluid and operating temperature are within the rated limits of SBR rubber before use.

Technical Specifications

• Material: SBR (Styrene-Butadiene) Rubber
• Color: Red
• Thickness: 1/16 inch
• Length: 33 feet
• Maximum Service Temperature: 160 degrees F
• Oil Resistance: Limited
• Package Type: Bulk spool

Standard Information

• Brand: RUBBER
• Manufacturer Part Number: r82005001
