Rosslare AC-425IP-BU Enclosed Expandable Networked Access Control for 4 Readers TCP/IP

Product Description

The ROSSLARE AC-425IP-BU is an enclosed expandable networked access control system designed for 4 readers, utilizing TCP/IP for connectivity. It features a mountable and lockable metal enclosure and supports up to 30,000 users in off-line mode, with unlimited server-based capacity. The system records 20,000 event history entries per computer and supports multi-user authentication for enhanced security. It is compatible with a wide range of Wiegand and PIN formats.

• Mountable & lockable metal enclosure.
• Supports up to 30,000 users in off-line mode, unlimited server based capacity.
• 20,000 event history entries per computer.

Product Highlights

Expandable networked access control system for enhanced security and supports a wide range of Wiegand and PIN formats.

Product Information

Standard Information

• Brand: ROSSLARE
• Manufacturer Part Number: AC-425IP-BU

Technical Specifications

• Type: Network Control Panel
• Readers: 4 reader ports (6-wire)
• Output Voltage: 12 VDC
• Max. Current: 245 mA
• Inputs: 4 supervised high impedance inputs. 8 or 12 supervised inputs when using MD-D04B or MD-IO84B expansion boards Maximum voltage: 5 VDC
• Outputs: 4 Form C 5 Amp relay outputs. 8 outputs when using MD-D04B or MD-IO84B expansion boards
• Interface: TCP/IP
• Serial Ports: 10/100 Ethernet Port
• Networking: Rosslare's AxTraxNGâ„¢ Server
• Users: 30,000 active credentials (Card & PIN)
• Event Log: 20,000 Events
• Housing: ME-1015 Power Management Enclosure
• Standard Approvals: CE - Safety, ENC, RFI, LVD RED 2104/53/EU; FCC - CFR47 Part 15b
• Model: ROSSLARE AC-425IP-BU B SERIES
• MPN: AC-425IP-BU
• Brand: Rosslare
• Groups: 30000
• Product Type: Scalable Networked Access Control Panel
• Supports: 4 Readers
• Expandable: to 8 readers with MD-D04B module
• High Capacity: Manages 30,000 users, 128 access groups, and 128 time zones
• Modular Design: Includes expansion options for additional readers, inputs, and outputs
• Reliable: Features non-volatile memory and real-time clock with up to 24-hour backup
• Advanced Connectivity: Offers TCP/IP and RS-485 connections for up to 1023 panels
