ROMEX ROMEX6/3W/GRD1000R NM-B 6/3 Copper w/Ground (1000 ft) Replacement MPN

Product Description

ROMEX NM-B 6/3 Copper w/Ground Non-Metallic Sheathed Branch Circuit Cable is suitable for residential wiring projects. This cable is used for branch circuits connecting outlets, lighting, switches, and various loads. It is applicable for both exposed and concealed installation in dry locations. It can also be routed through air voids in masonry block or tile walls under non-moist conditions.

• Designed for residential wiring including outlets and lighting.
• Rated for 600 volts with a conductor temperature rating of 90 degrees Celsius (dry).
• Constructed with copper conductors and features a SIMpull Cable Jacket for easier installation.

Product Highlights

This cable is LEAD FREE and RoHS compliant. It is engineered for durability and safety in wiring applications.

Product Information

Standard Information

• Country of Origin: USA
• Color: Black, White, Red

Technical Specifications

• Conductor Material: Copper
• Conductor Size: 6 AWG
• Current (Allowable Ampacity): 55 Amp
• Insulation Material: PVC
• Number of Conductors: 3
• Stranding: 7 Strand
• Temperature Rating: 90 degrees C (DRY)
• Type: NM-B
• Voltage: 600 Volt
• Ground Wire Size: 10 AWG
• Outer Diameter: 650 mil
• PVC Insulation Thickness: 0.029 inches / 0.76 mm
• Nylon Thickness: 0.005 inches / 0.13 mm
• Jacket Thickness: 30 mils / 0.76 mm
