ROMEX ROMEX6/2W/GRD500R NM-B 6/2 Copper w/Ground Non-Metallic Sheathed Branch Circuit Cable 500ft Reel

Product Description

The ROMEX NM-B 6/2 Copper w/Ground Non-Metallic Sheathed Branch Circuit Cable is intended for general use in residential and commercial settings. It consists of two 6 AWG copper conductors and a ground wire, all wrapped in durable PVC insulation. The cable supports a maximum voltage rating of six hundred volts and can handle temperatures up to ninety degrees Celsius in dry applications.

• Features two copper conductors and a ground wire.
• Insulated with PVC for added durability.
• Rated for six hundred volts and ninety degrees Celsius (dry applications).

Product Highlights

This cable is ideal for both concealed and exposed installations, ensuring compliance with electrical codes.

Product Information

Standard Information

• Conductor Material: Copper
• Conductor Size: 6 AWG

Technical Specifications

• Current: 55 Amp
• Insulation Material: PVC
• Number of Conductors: 2
• Stranding: 7 Strand
• Temperature Rating: 90 degrees Celsius (DRY)
• Type: NM-B
• Voltage: 600 Volt
