Romex romex2/3w/grdmr Nm-b 2 Awg 3-conductor Cable

Product Description

The ROMEX romex2/3w/grdmr is a 2 AWG, 3-conductor NM-B non-metallic sheathed cable with ground, designed for residential and light commercial branch circuit wiring. The cable features a 7-strand copper conductor construction rated for 95 amps and 600 volts, with PVC insulation and a nylon jacket that meets NM-B type requirements. It carries a 90 degrees C temperature rating, making it suitable for standard branch circuit applications inside conditioned spaces. This product is sold cut to length and is intended for installation by licensed electricians in compliance with applicable electrical codes.

This cable is used in residential branch circuit wiring where NM-B type cable is permitted by the National Electrical Code. Common applications include heavy-duty circuits serving large appliances, HVAC equipment, or subpanel feeds within a structure. The 2 AWG conductor size and 95-amp current rating accommodate higher-load circuits. The nylon jacket provides added abrasion resistance during installation through framing and penetrations. This is a cut-to-length product, allowing techs to order the exact footage needed for a given run.

Key Features

• 2 AWG 7-strand copper conductors for high-current branch circuit use
• 95-amp current rating at 600 volts
• NM-B type with PVC insulation and nylon outer jacket
• 90 degrees C temperature rating
• 3-conductor with ground configuration
• Cut-to-length ordering for job-specific quantities

Compatibility

Designed as an NM-B type non-metallic sheathed cable for use in branch circuit wiring applications where NM-B cable is permitted per applicable electrical code requirements.

Installation Notes

Installation must be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and applicable local codes. Always de-energize the circuit and verify zero voltage with a meter before making any terminations. NM-B cable is permitted only in dry locations within a structure and must not be installed in conduit, exposed in plenums, or in locations where the jacket could be subject to physical damage without additional protection. Secure and support the cable per NEC requirements for NM-type wiring.

Technical Specifications

• Type: NM-B
• Conductor Material: Copper
• Conductor Size: 2 AWG
• Number of Conductors: 3 with Ground
• Stranding: 7 Strand
• Current Rating: 95 amps
• Voltage Rating: 600 volts
• Temperature Rating: 90 degrees C
• Insulation Material: PVC
• Jacket Material: Nylon
• Outer Diameter: 0.945 inches
• Weight: 841 pounds per 1000 feet

Standard Information

• Brand: ROMEX
• Manufacturer Part Number: romex2/3w/grdmr
