Romac 286-090532 Double Strap Saddle 8 in 3/4 in Fipt

Product Description

The ROMAC 286-090532 is a double strap pipe saddle designed for tapping into 8-inch steel or cast iron water mains. The saddle body is constructed from nylon with stainless steel straps, providing corrosion resistance and mechanical strength in buried or exposed service conditions. The outlet is a 3/4-inch female iron pipe thread (FIPT) connection, rated to a maximum of 350 psi. This fitting is used by licensed plumbers and waterworks contractors to create a new branch connection on an existing main without replacing the pipe. It meets AWWA C-800 standards for underground service line fittings.

This saddle is intended for use on 8-inch steel or cast iron pipe in municipal water distribution, commercial site work, and industrial piping systems. The double strap design distributes clamping load evenly around the pipe, making it well suited for pressurized service applications. The FIPT outlet accepts a standard corporation stop or ball valve for service line installation. Licensed plumbing and waterworks contractors are the primary installers of this type of fitting in both new construction and repair tapping applications.

Key Features

• Stainless steel double straps for even clamping on 8-inch pipe
• Nylon saddle body resists corrosion in buried and wet service environments
• 3/4-inch FIPT outlet connection for direct valve or corporation stop makeup
• Rated to 350 psi maximum working pressure
• Meets AWWA C-800 standard for underground service line fittings
• Compatible with steel and cast iron pipe

Compatibility

Designed for use on 8-inch steel or cast iron pipe. Outlet connection is 3/4-inch FIPT, suitable for standard corporation stops and service line valves used in AWWA C-800 compliant waterworks installations.

Installation Notes

Installation should be performed by a licensed plumber or waterworks contractor in accordance with local codes and AWWA standards. Depressurize or isolate the line section when possible before drilling and tapping. Torque the stainless steel straps evenly to seat the nylon body flush against the pipe surface. Inspect the FIPT outlet threads before making up the valve or corporation stop connection to avoid cross-threading.

Technical Specifications

• Fits Pipe Size: 8 inches
• Tap Size: 3/4 inches
• End Connection: FIPT
• Maximum Pressure: 350 psi
• Saddle Body Material: Nylon
• Strap Material: Stainless Steel
• Compatible Pipe Material: Steel, Cast Iron
• Standard: AWWA C-800

Standard Information

• Brand: ROMAC
• Manufacturer Part Number: 286-090532
