Romac 286-048042 Double Strap Saddle 4 in Pipe 1 in Fipt

Product Description

The ROMAC 286-048042 is a double strap pipe saddle designed for tapping into 4-inch steel or cast iron water mains. The saddle body is constructed from nylon with stainless steel straps, combining corrosion resistance with mechanical strength. It accepts a 1-inch female iron pipe thread (FIPT) tap connection and is rated to 350 psi maximum working pressure. This fitting is installed by licensed plumbers and waterworks contractors during service line taps, branch connections, and main line repairs on pressurized distribution systems.

This saddle is suited for municipal water distribution, industrial piping, and commercial plumbing applications where a reliable branch tap is needed on 4-inch steel or cast iron pipe. The FIPT outlet accommodates standard threaded service line fittings, making it compatible with typical corporation stop and service valve installations. It conforms to AWWA C-800, making it appropriate for potable water service work.

Key Features

• Stainless steel double strap design provides secure clamping on 4-inch steel or cast iron pipe
• Nylon saddle body resists corrosion in buried and wet service environments
• 1-inch FIPT tap outlet accepts standard threaded fittings and corporation stops
• Rated to 350 psi maximum working pressure
• Meets AWWA C-800 standard for underground service line fittings

Compatibility

Designed for use on 4-inch steel or cast iron pipe. Outlet connection is 1-inch FIPT. Conforms to AWWA C-800 for potable water service applications.

Installation Notes

Installation is typically performed by licensed plumbers or waterworks technicians. Depressurize or isolate the line where possible before drilling and tapping, following local water authority procedures. Ensure strap torque is applied evenly to seat the saddle body flush against the pipe OD before tapping. All work on potable water mains should comply with applicable local plumbing codes and AWWA standards.

Technical Specifications

• Fits Pipe Size: 4 inches
• Tap Size: 1 inch
• End Connection: FIPT
Maximum Pressure: 350 psi
• Strap Material: Stainless Steel
• Body Material: Nylon
• Standard: AWWA C-800

Standard Information

• Brand: ROMAC
• Manufacturer Part Number: 286-048042
