Rockwell Automation 20G1AND186JA0NNNNN PowerFlex 755 AC Drive

Product Description

The Rockwell Automation 20G1AND186JA0NNNNN is a PowerFlex 755 AC Drive designed for versatile applications in industrial environments. This drive has an embedded Ethernet/IP interface and provides standard protection features. The unit has forced air cooling and operates with an AC input including precharge systems. It does not include DC terminals and is categorized as open type. The drive supports up to one hundred eighty-six amps, ideal for one hundred fifty horsepower in normal duty and one hundred twenty-five horsepower in heavy duty at four hundred eighty volts with three-phase connectivity. This specific model is framed in six, includes filtered outputs, and has the CM jumper installed with a DB transistor. It is a blank unit with no human interface module (HIM).

• Embedded Ethernet/IP for network connectivity
• Standard protection features for reliable operation
• Forced air cooling to support thermal management

Product Highlights

The PowerFlex 755 AC Drive is suitable for a range of applications requiring robust performance and reliability. Its high current capabilities make it a strong choice for demanding tasks in industrial settings.

Product Information

Standard Information

• Brand: Rockwell Automation
• Part Number: 20G1AND186JA0NNNNN AB

Technical Specifications

• Rated Amperage: 186 Amps
• Horsepower Normal Duty: 150 HP
• Horsepower Heavy Duty: 125 HP
• Voltage: 480 VAC
• Phase: 3 PH
• Frame Size: 6
• Cooling Type: Forced Air
• DC Terminals: No
