Rockwell Automation 20F11ND096JA0NNNNN PowerFlex 753 AC Drive

Product Description

The Rockwell Automation 20F11ND096JA0NNNNN is a PowerFlex 753 AC drive. This drive features embedded I/O and is designed to handle standard protection requirements. The unit operates with forced air cooling and accepts AC input with DC terminals. The drive is open type, rated for ninety-six amps and up to seventy-five horsepower for normal duty, and sixty horsepower for heavy duty. It is suitable for three-phase applications at four hundred eighty volts.

• Rated for 96 amps and 75HP normal duty.
• Includes filtered input and a CM jumper installed.
• DB transistor configuration without a human machine interface.

Product Highlights

This drive is appropriate for various industrial applications and supports multiple configurations. Its robust design suits both light and heavy-duty operations.

Product Information

Standard Information

• Brand: Rockwell Automation
• MPN: 20F11ND096JA0NNNNN

Technical Specifications

• Input Type: AC with DC terminals
• Cooling Type: Forced air
• Frame Size: 5
• Voltage: 480 VAC
• Power Rating: 75 HP ND, 60 HP HD
• Current Rating: 96 Amps
• Protection Type: Standard protection
• Accessories: Filtered input, CM jumper installed
