Robroy PRC57 Conduit Body, 1-1/2 Inch Mall PVC C Body

Product Description

The ROBROY PRC57 is a conduit body with a side access opening and a C configuration. It features a PVC-coated cover and a straight hub location with 2 hubs, each sized at 1-1/2 inches. Constructed with a 2 MIL red urethane ferrous metal interior and a 40 MIL gray PVC ferrous metal exterior, this Form 7 conduit body is suitable for connecting conduit sections and providing access to conductors.

• Features a PVC Coated Cover
• Constructed with 2 MIL Red Urethane Ferrous Metal Interior, 40 MIL Gray PVC Ferrous Metal Exterior
• Approved by ETL, UL 514A/D, UL (Canada and US), CSA C22.2

Product Highlights

This Robroy conduit body connects conduit sections and provides access to conductors for maintenance and system changes.

Product Information

Standard Information

• Brand: ROBROY
• Manufacturer Part Number: PRC57
• Country of Origin: United States of America

Technical Specifications

• Access Opening Side: Side
• Configuration: C
• Cover Type: PVC Coated
• Hub Location: Straight
• Number of Hubs: 2
• Hub Size: 1-1/2 Inch
• Size: 2.6 Inch H
• Installation: Screw
• Material: Steel
• Form Type: Form 7
• Approval: ETL, UL 514A/D, UL (Canada and US), CSA C22.2
• Trade Size: 1-1/2 Inch
• Standards: CSA C22.2 No. 42, C22.2 No.18 Certified, UL 514A, 514D, E231035 Listed, ISO 9001-2015 Certified
• Conduit Body Style: Type C
• Conduit Body Form: Form 7
• Sub Brand: Plasti-Bond, REDH2OT®
• Connection Type: Threaded
• Finish: 40 mil Gray PVC Coated Exterior, 2 mil Red Urethane Coated Interior
• Made In America: Yes
• Item Name: Conduit Body With Cover
• Country Of Origin: United States of America
• Manufacturer Part Number: PRC57
• RoHS Flag: Yes
• Energy Star Flag: No
• UPC: 78401120349
• Manufacturer Name: Robroy
• GTIN: 00784011203499
• UNSPSC: 39131708
• Product Series: General Service
• Shape: C
• Cover Included: Yes
• Gasket Included: No
• Conduit Type: RMC (Rigid Metal Conduit)
• Composition: Malleable Iron
• Approvals: cULus
• Comments: PVC Exterior Coating
• Applications: Electrical and Data wire raceways in harsh environments
• Connector Type: Threaded
• Split Crucible: S
• Type: FITTING
• Brand: Robroy Industries
• 12-Digit UPC: 784011203499
• Buy American Compliant: Y
• Access Opening: Side
