RANCO O16-624 Single Pressure Control, Low Pressure, Auto Operation, IP54 - Replacement O16-624

Product Description

Explore the robust Ranco O16-624 Single Pressure Control, designed to safeguard compressors from refrigerant loss and regulate commercial refrigeration cycles through its low pressure control mechanism. Built to support a wide range of refrigerants, this device is essential for maintaining optimal operation in cooling systems.

• Automatic reset functionality for continuous operation
• Durable enclosure with NEMA 1 rating ensures protection against external elements
• Adjustable pressure settings from 12 psi to 80 psi with a differential from 5 psi to 38 psi

Product Highlights

Featuring a 36-inch capillary length and a 1/4 inch SAE flare nut connection, the Ranco O16-624 is built for easy installation and reliable performance in harsh environments. Its SPST switch action opens on low pressure, making it an ideal choice for various commercial HVAC systems, including refrigerators, freezers, and air compressors.

Technical Specifications

• Pressure Range: 12 to 80 psi
• Capillary Length: 36 inches
• Connection Type: 1/4 inch SAE flare nut
• Switch Type: SPST
• Enclosure: IP54 rated
