Robertshaw 780-001 Universal Ignition Module for Residential and Commercial Heating - 24VAC

Product Description

The Robertshaw 780-001 Universal Ignition Module efficiently manages residential and commercial heating systems. Ensuring robust performance with its advanced flame sense technology, this module supports both one rod and two rod sensing applications.

• High adaptability with 24 VAC, 50/60 Hz, and 1.5 A specifications suitable for various setups.
• Automatic recycling for enhanced safety in flame failure situations.
• Non-lockout feature ensures continuous operation without manual reset.

Product Highlights

Designed for durability and reliability, the Robertshaw 780-001 offers secure and efficient ignition control. Its universal application allows easy integration with a wide range of heating systems.

Product Information

Standard Information

• Input Voltage: 24 VAC to 50/60 Hz
• Transformer: 24 VAC / 20 VA

Technical Specifications

• Spark Rate: 3 to 4 sparks per second
• Pilot Valve: 1 amp at .5 PF
• Main Valve: 1 amp at .5 PF
• Combined Load: 1.5 at .4 PF
• Flame Sense Current: .7 μA DC @ 25°C / 24 VAC
• Max. Total Current: 1.5 amp
• Flame Failure Recognition Time: .8 seconds maximum
• Thermostat Anticipator Setting: .7 amp
• Ambient Temperature Rating: -40 to 175°F (-40 to 80°C)
• Relative Humidity: 95% noncondensing at 104°F
