Robertshaw 35-605601-001 Ignition Control Module

Product Description

The Robertshaw 35-605601-001 is an ignition control module for gas burner systems. This device uses a microprocessor to efficiently manage gas burner operation. It offers precise timing sequences for ignition and purge cycles.

• On-board diagnostics with LED output for troubleshooting.
• Automatic reset functionality enhances safety and reliability.
• Supports flame sensing during pre-purge with one ignition attempt before lockout.

Product Highlights

This module is essential for maintaining safe and effective gas burner operation.

Product Information

Standard Information

• Brand: Robertshaw
• Model: 35-605601-001

Technical Specifications

• Electrical Rating: 24V AC 300 mA
• Connection Type: Edge Connector
• Flame Sensor Method: Local
• Construction: Gray Noryl
• Ignition Attempts Before Lockout: 1
• Trial for Ignition: 4
• Gas Valve Rating: 2.0 Amps at 24V AC
• Auto Restart: Yes
• Auto Reset: Yes
• Control Voltage: 18-30V AC 50/60 Hz
