Robertshaw 3450-003 Motor Protector

Product Description

The Robertshaw 3450-003 Motor Protector safeguards equipment by monitoring PTC sensor resistance, automatically shutting down if stator winding temperature exceeds the trip point. It features a 2-minute delay on pause to prevent short cycling and allows pressure equalization. A constant low voltage monitoring circuit ensures shutdown if supply voltage drops below the minimum, preventing restarts until conditions are met. It also eliminates nuisance shutdowns from voltage spikes.

• Automatic shutdown based on PTC sensor resistance if stator winding temperature exceeds trip point.
• Automatic restart after cooling, provided delay and voltage reset requirements are met.
• Constant low voltage monitoring circuit designed for automatic equipment shutdown.

Product Highlights

Protects motors from overheating and low voltage conditions with automatic shutdown and controlled restart.

Product Information

Standard Information

• Brand: ROBERTSHAW
• Manufacturer Part Number: 3450-003

Technical Specifications

• Manufacturer: Robertshaw
• Part Number: 3450-003
