Rivetking /XTM312008SZ/P100 Semi Tubular Rivet 100 Pack

Product Description

The RIVETKING /XTM312008SZ/P100 is a round-head semi tubular rivet manufactured from zinc plated steel. Semi tubular rivets feature a partial hole in the shank, which reduces the setting force required compared to solid rivets. This makes them well-suited for light-to-medium duty fastening applications where a clean, flush-looking head is needed on the visible face. The body diameter measures 9/64 inches, the head diameter is 5/16 inches (0.3125 inches), and the length under head is 1/4 inches. Minimum hole diameter is 0.1 inches and maximum hole diameter is 0.107 inches. Each package contains 100 rivets. Installation is performed by tool-and-die or rivet setting equipment.

These zinc plated steel semi tubular rivets are used in light sheet metal assembly, electrical enclosures, appliance manufacturing, HVAC cabinet fabrication, and general industrial fastening. The round head profile seats flush against the work surface and distributes load over the 0.3125-inch head diameter. The zinc plating provides baseline corrosion resistance for indoor and light-exposure environments. This package quantity of 100 pieces is appropriate for bench-level production work or service-call restocking.

Key Features

• Round head profile with 0.3125 inch (5/16 inch) head diameter for broad load distribution
• Semi tubular shank design reduces required setting force compared to solid rivets
• Zinc plated steel construction provides corrosion resistance in indoor and light-exposure conditions
• Compatible with hole diameters from 0.1 inches to 0.107 inches
• 1/4 inch length under head and 9/64 inch body diameter for light-to-medium gauge material fastening
• Sold in a 100-piece package to support production and service work

Compatibility

Designed as a standard semi tubular rivet for light sheet metal, appliance, HVAC cabinet, and general industrial assembly applications requiring a 0.1 to 0.107 inch hole diameter and a round head profile.

Installation Notes

Semi tubular rivets are set using a rivet setter or press with a die matched to the head style and shank diameter. Ensure the work material hole diameter falls within the 0.1 to 0.107 inch specified range before setting. Inspect the set rivet for a fully rolled shank with no cracking before considering the joint complete. Handle zinc plated fasteners with care to avoid coating damage that could accelerate corrosion.
