Rivetking /SBS812CM/SET/P10 Blind Rivet 8-12 Steel 10 Pack

Product Description

The RIVETKING /SBS812CM/SET/P10 is a flush-on-both-sides blind rivet designed for applications where a smooth surface finish is required on both the shop head and the blind side. Built with a steel body and steel mandrel, this size 8-12 rivet features a dome head profile and a body diameter of 0.25 inches. It accepts a grip range of 0.625 to 0.75 inches, making it well-suited for joining material stacks within that range. The minimum hole diameter is 0.255 inches. This rivet is installed by licensed or journeyman-level tradespeople and industrial assemblers working in metal fabrication, HVAC ductwork, panel assembly, and structural fastening applications. This package contains 10 rivets.

This blind rivet is used in applications where access is limited to one side of the workpiece. The flush-on-both-sides design provides a low-profile, smooth finish on the installed face as well as the back side, which is critical in visible panel work, duct assembly, and sheet metal enclosures. The 8-12 size code indicates a body diameter in the 8 series with a grip length in the 12 series, guiding selection for common sheet metal thicknesses found in residential and light commercial construction and fabrication work.

Key Features

• Flush finish on both shop head and blind side for clean panel and duct installations
• Steel body and steel mandrel for reliable tensile and shear strength in metal-to-metal fastening
• Dome head profile with a head diameter of 0.625 inches and head height of 0.1 inches
• Grip range of 0.625 to 0.75 inches accommodates common sheet metal stack thicknesses
• Body diameter of 0.25 inches fits a minimum hole diameter of 0.255 inches
• Packaged in a 10-count set for small-quantity jobsite or repair use

Compatibility

Designed for use in standard blind rivet applications requiring a 0.255-inch minimum hole diameter and a grip range of 0.625 to 0.75 inches. Compatible with manual, pneumatic, and hydraulic rivet tools configured for 1/4-inch body diameter rivets.

Installation Notes

Install using a rivet tool rated for 1/4-inch body diameter blind rivets. Drill or punch the mating hole to a minimum diameter of 0.255 inches before insertion. Ensure the workpiece stack falls within the 0.625 to 0.75 inch grip range for a proper clinch. Do not exceed the maximum grip range, as an undersized stack will result in an incomplete or weak set.
