Rittal 3108115 Sk Series Enclosure Internal Fan 100 Cfm

Product Description

The RITTAL 3108115 is an internal enclosure fan from the SK Series, designed to provide active air circulation inside electrical enclosures and control cabinets. Rated at 115 VAC and delivering 100 CFM of airflow, this radial fan helps regulate internal temperatures to protect sensitive components from heat buildup. Drawing 0.23/0.24 A at 19/18 W depending on frequency, it ships as a complete unit ready for connection and includes a snap-on pivot device and mounting fasteners. Installation is straightforward for electricians and panel builders working on climate control solutions in industrial and commercial settings.

This fan is suited for use in electrical enclosures requiring active internal climate control. It is part of the SK Series product line, which targets professional enclosure climate management applications. Typical use cases include switchgear panels, control cabinets, and distribution enclosures where passive ventilation alone is insufficient. The fan mounts internally and uses a radial design to direct airflow efficiently across heat-generating components.

Key Features

• 100 CFM airflow rating for effective internal enclosure cooling
• 115 VAC input voltage suits standard North American panel power
• Low power draw of 19/18 W minimizes load on enclosure circuits
• Ships as a complete unit with radial fan, snap-on pivot device, and fasteners
• RoHS compliant construction
• Part of the RITTAL SK Series climate control product line

Compatibility

Designed as an OEM-style internal fan for electrical enclosures requiring active air circulation, typical of SK Series climate control installations.

Installation Notes

Installation should be performed by a qualified electrician or panel builder. Disconnect and lock out all power to the enclosure before mounting or wiring the fan. The snap-on pivot device and included fasteners allow secure internal mounting without additional hardware. Follow applicable NEC requirements for enclosure wiring and ventilation when integrating this unit into a panel or switchgear assembly.

Technical Specifications

• Voltage Rating: 115 VAC
• Amperage Rating: 0.23/0.24 A
• Power Rating: 19/18 W
• Air Flow Rate: 100 CFM
• Width: 4.72 inches
• Height: 8.40 inches
• Series: SK Series
• Includes: Complete unit with radial fan ready for connection, snap-on pivot device and fasteners
• Compliance: RoHS Compliant

Standard Information

• Brand: RITTAL
• Manufacturer Part Number: 3108115
