Rittal 1260000 Wallmount Enclosure, 1 Door, Gland Plate, 48x24x12

Product Description

The RITTAL 1260000 AX compact enclosure features embossed enclosure cams in the roof, base, and side, replicating the 25 mm system grid from the VX25 large enclosure. This patented system prepares AX compact control enclosures for expansion and retrofitting. System components and accessories can be installed quickly and safely on rails without drilling.

• Integrated housing cams in the 25 mm system grid
• Maintains protection class with interior installation rail
• Additional mounting level and increased load capacity due to base configuration rail

Product Highlights

The RITTAL 1260000 AX enclosure offers maximum data quality, flexibility, and safety in assembly and interior installation.

Product Information

Standard Information

• Brand: RITTAL
• Manufacturer Part Number: 1260000

Technical Specifications

• Brand: RITTAL
• Manufacturer Part Number: 1260000
• Series: AX Series
• UPC Code: 639889914766
• Material: Carbon Steel
• Surface finish: Housing and door: Dipcoat primed, powder-coated on the outside, textured paint Mounting panel: Zinc-plated
• Color: RAL 7035
• Supply includes: Housing with door(s) Flange (gland) plate(s) in enclosure base Mounting panel Punched door strip Lock: 3 mm double-bit
• Protection category NEMA: NEMA 1 NEMA 3R NEMA 4 NEMA 12
• Protection category IP to EN 60 529: IP 66
• Type rating according to UL 50E: Type 1 Type 3R Type 4 Type 12
• IK code: IK10
• Width: 600 mm
• Height: 1200 mm
• Depth: 300 mm
• Material thickness - door: 2 mm
• Material thickness - enclosure: 1.5 mm
• Material thickness – mounting plate: 2.5 mm
• Dimensions of mounting plate (W x H): 545 mm × 1,175 mm
• Number of doors: 1
• Interchangeable door catch: Yes
• Lock version: 3-point locking system
• No. of locks: 1
• Lock Insert: 3 mm double-bit
• Gland plate Size: 7
• Gland plate Qty.: 1
• Base material: Carbon steel
• Packaging unit: 1 pc(s).
• Net weight: 45.4 kg
• Gross weight: 50 kg
• Customs tariff number: 94032080
• EAN: 4028177813274
• ETIM 9: EC000261
• ETIM 8: EC000261
• ECLASS 8.0: 27180101
• Enclosure Lock Type: Sold Separately
• Enclosure NEMA Rating: NEMA Type 1
• Enclosure Height: 47.2"
• Manufacturer: Rittal
• Line: WM
• Enclosure Width: 23.6"
• Enclosure Depth: 11.8"
• Enclosure Door Type: Solid
• Enclosure Mount Type: Wall Mount
• Enclosure Composition: Steel
• Component: Steel Enclosure
• Enclosure Number of Doors: 1 Door
• NEMA: 4
• Lock: 3 mm Double-Bit Cam
• Voltage: 1000 VAC/1500 VDC
• Seal: Foamed-In PU Seal
• Mount: Wall Mount
• Temperature: -20 to 80 deg C
• Coating: Powder Coated
• Content: 1 pc(s)
• Product type: Switchboard cabinet
