Ritchie Engineering 69075 LCD Vacuum Gauge Kit

Product Description

The Ritchie Engineering 69075 is an LCD vacuum gauge kit designed for accurate vacuum measurements. The overall dimensions are twelve and a half inches in length, nine inches in depth, and two point thirty-seven inches in height. This gauge features a zero point five inch LCD display with battery check capability. It offers a response time of three seconds and includes a five point five foot coiled sensor cable that connects through a one quarter inch male flare.

• Automatic calibration for enhanced accuracy
• Temperature range between thirty-two and one hundred twenty degrees Fahrenheit
• Powered by D cell batteries lasting up to seventy hours

Product Highlights

This kit includes the 69102 LCD vacuum gauge, along with the 69058 cord, 69073 sensor, and 69071 connector. The unit is designed to resist normal handling and jarring, ensuring stable readings. The case protects the internal circuitry and sensor, and the calibration standards are traceable to NIST. It features an automatic shut-off that activates twenty minutes after powering on without any changes.

Product Information

Standard Information

• Brand: Ritchie Engineering
• Part Number: 69075

Technical Specifications

• Overall Dimensions: 12.5 inches length x 9 inches depth x 2.37 inches height
• Display: 0.5 inch LCD
• Response Time: 3 seconds
• Calibration: Automatic
• Sensor Cable Length: 5.5 feet
• Connection Type: 1/4 inch male flare
• Temperature Rating: 32 to 120 degrees Fahrenheit
• Power Source: D cell battery (70 hours)
• Accuracy: +/- 20 percent
