Product Description
The Rinnai V53DEN Value Series tankless water heater delivers a combination of comfort and value. Designed for outdoor installation, this natural gas unit provides an endless supply of hot water on demand. It features a compact design for easy installation and frees up valuable space. The electric ignition avoids wasted energy from a standing pilot light.
- Compact Design
- Energy-Efficient Promise
- Continuous Water for Multiple Applications
Product Highlights
This tankless water heater is energy-efficient, space-saving, and provides continuous hot water for residential applications. It is AHRI and CSA certified.
Product Information
Standard Information
-
Brand: RINNAI
-
Manufacturer Part Number: V53DEN
-
Country of Origin: Japan
Technical Specifications
-
Fuel Type: Natural Gas
-
UPC: 766156011795
-
Phase: 1
-
Voltage: 120 Volts
-
Product Depth: 7.9 in
-
Product Width: 14.0 in
-
Type: Tankless Water Heater
-
CSA Listed: Yes
-
Product Height: 21.8 in
-
Frequency: 60 Hz
-
Product Category: Water Heater - Tankless
-
Medium: Hot Water
-
Cold Water Inlet: 3/4 Inch
-
Hot Water Outlet: 3/4 Inch
-
NSF Certified: Yes
-
AHRI Certified: Yes
-
Vent Type: Vent Free
-
Minimum Flow Rate: 0.4 GPM
-
Gas Connection Size: 3/4 Inch
-
Mount Type: Wall
-
Application: Residential
-
Product Line: Value Series
-
Storage Type: Tankless
-
Includes Pump: No
-
Uniform Energy Factor: 0.81
-
Maximum Input Capacity: 120000 BTU
-
Minimum Input Capacity: 15500 BTU
-
Combustion Type: Non-Condensing
-
Ultra Low NOx Emissions: Yes
-
Product Sub-line: High Efficiency (HE)
-
Gas Conversion Kit: Not Available
-
Installation Location: Outdoor
-
Flow Rate at 40F Temperature Rise: 4.9 GPM
-
Flow Rate at 45F Temperature Rise: 4.4 GPM
-
Flow Rate at 50F Temperature Rise: 3.9 GPM
-
Flow Rate at 60F Temperature Rise: 3.3 GPM
-
Flow Rate at 70F Temperature Rise: 2.8 GPM
-
Energy Factor: 0.82
-
BTU (Max): 120000
-
BTU (Min): 15500
-
Max Flow (GPM): 5.3
-
Min Flow (GPM): 0.3 GPM
-
Depth (Inches): 8"
-
Height (Inches): 22.5"
-
Width (Inches): 14"
-
Energy Star Rated: No
-
Installation Type: Outdoor Only
-
Cold Water Inlet (NPTM): 3/4"
-
Hot Water Outlet (NPTF): 3/4"
-
Gas Connection: 3/4"
-
Dimensions: H: 21.8 in
-
W: 14 in
-
D: 7.9 in
-
Manufacturer Trade Model Number - U.S.: V53DeN
-
Recirculation Capable: No
-
Residential Energy Star: No
-
Domestic Hot Water Flow Rate (Maximum): 5.3 GPM 20.1 l/min
-
Wi-Fi Capable: Yes
-
SCAQMD Approved: Ultra Low NOx
-
Activation GPM: 0.6
-
Maximum Flow Rate: 5.3 GPM
-
Minimum Gas Input: 15000
-
Water Connection: 3/4"
-
Water Pressure (Max): 150 PSI
-
Water Pressure (Min): 20 PSI
-
Max BTU Input: 120000
-
Natural Gas Thermal Efficiency: 0.82
-
Temperature (Max): 140 °F
-
Temperature (Min): 115 °F
-
Heating Technology: Non-Condensing
-
Water Connection Type: MNPT
-
Manufacturer Technology: Recirculation
