Product Description
The Rinnai RUS65EN from the Ultra Series delivers a combination of comfort and efficiency. This natural gas tankless water heater provides hot water on demand with a maximum input capacity of 130000 BTU. Designed for outdoor residential applications, it features a compact design and easy maintenance.
- Compact Design for discreet installation.
- Saves energy by only heating water when needed.
- Provides continuous, uninterrupted hot water.
Product Highlights
The Rinnai RUS65EN tankless water heater offers an efficient and space-saving solution for continuous hot water supply in residential settings.
Product Information
Standard Information
-
Brand: RINNAI
-
Manufacturer Part Number: RUS65EN
-
Country of Origin: Japan
Technical Specifications
-
Fuel Type: Natural Gas
-
Type: Tankless Water Heater
-
CSA Listed: Yes
-
Frequency: 60 Hz
-
Product Category: Water Heater - Tankless
-
Medium: Hot Water
-
Cold Water Inlet: 3/4 Inch
-
Hot Water Outlet: 3/4 Inch
-
NSF Certified: Yes
-
AHRI Certified: Yes
-
Vent Type: Outdoor (No Venting)
-
Minimum Flow Rate: 0.4 GPM
-
Gas Connection Size: 3/4 Inch
-
Mount Type: Wall
-
Application: Residential
-
Product Line: Ultra Series
-
Storage Type: Tankless
-
Includes Pump: No
-
Uniform Energy Factor: 0.90
-
Maximum Input Capacity: 130000 BTU
-
Minimum Input Capacity: 10300 BTU
-
Combustion Type: Condensing
-
Ultra Low NOx Emissions: Yes
-
Parts Warranty: 5 Years
-
AHRI Reference Number: 8203412
-
Gas Conversion Kit: Not Available
-
Installation Location: Outdoor
-
Heat Exchanger Warranty: 12 Years
-
Flow Rate at 40F Temperature Rise: 6.0 GPM
-
Flow Rate at 45F Temperature Rise: 5.2 GPM
-
Flow Rate at 50F Temperature Rise: 4.8 GPM
-
Flow Rate at 60F Temperature Rise: 4.0 GPM
-
Flow Rate at 70F Temperature Rise: 3.4 GPM
-
Phase: 1
-
Voltage: 120 Volts
-
Maximum Flow Rate: 6.5 Gallons Per Minute
-
Applicable Standard: ANSI Z21.10.3, CSA 4.3, AHRI
-
Electrical Input Supply Rating: 120 Volt AC at 60 Hertz, 12 Volt DC, 2.3 Amp, 61 Watt
-
Gas Input Supply Rating: 10300 to 130000 BTU/Hour
-
Ignition Type: Direct Electronic
-
Inlet/Outlet Connection: 3/4 Inch Threaded x 3/4 Inch Threaded
-
Temperature Rating: 120 to 140 Deg F
-
Energy Factor: 0.93
-
Flow Range (GPM): 0.26 - 6.5
-
Energy Star Rated: Yes
-
Temperature Range (F): 120°F to 140°F
-
Cold Water Inlet (NPTM): 3/4"
-
Hot Water Outlet (NPTF): 3/4"
