Ridgid RIG31045 Heavy-duty Straight Pipe Wrench 60 in

Product Description

The RIDGID RIG31045 is a heavy-duty straight pipe wrench built for demanding plumbing and pipefitting work. Constructed with a cast-iron housing and an I-beam handle, it delivers the structural rigidity needed for high-torque applications on large-diameter pipe. The wrench measures 60 inches in overall length and handles pipe up to 8 inches in capacity. Both the hook jaw and heel jaw are replaceable, extending tool life and reducing downtime in the field. Self-cleaning threads on the adjusting mechanism help keep the jaw tracking smoothly even in dirty job site conditions.

This pipe wrench is suited for commercial and industrial plumbing installations, large-diameter pipe assemblies, and heavy mechanical work where a standard wrench lacks the reach or bite. The 60-inch overall length provides the leverage required for turning stubborn or large-diameter fittings and couplings. Licensed plumbers, pipefitters, and mechanical contractors are the primary users of a tool at this size class.

Key Features

• Cast-iron housing and I-beam handle for high-torque rigidity
• Full floating forged hook jaw for consistent bite on round pipe
• Self-cleaning threads keep jaw adjustment smooth under dirty conditions
• Replaceable hook and heel jaws reduce long-term tool cost
• Complies with federal specification GGG-W65IE, Type II, Class A
• 60-inch overall length provides substantial mechanical leverage

Compatibility

Designed as a heavy-duty straight pipe wrench for use on pipe up to 8 inches in diameter, suitable for large-diameter plumbing and pipefitting applications.

Installation Notes

This tool is typically used by licensed plumbers and pipefitters on pressurized piping systems. Shut off and depressurize any line before breaking connections. Jaw direction matters — always position the wrench so the load bears against the heel jaw to maintain grip. Inspect hook and heel jaws regularly and replace worn jaws before use to prevent jaw slip under load.

Technical Specifications

• Overall Length: 60 inches
• Pipe Capacity: 8 inches
• Handle Design: I-beam
• Housing Material: Cast iron
• Jaw Type: Full floating forged hook jaw with replaceable hook and heel jaws
• Federal Specification: GGG-W65IE, Type II, Class A
• Weight: 47.18 pounds
• Sold As: Each

Standard Information

• Brand: RIDGID
• Manufacturer Part Number: RIG31045
