Ridgid RIG31000 Straight Pipe Wrench 6 Inch

Product Description

The RIDGID RIG31000 is a heavy-duty straight pipe wrench designed for gripping and turning pipe in plumbing, HVAC, and mechanical piping applications. Built on a cast-iron housing with an I-beam handle, it accepts pipe and round stock up to 3/4 inch and measures 6 inches in overall length. The full floating forged hook jaw maintains consistent grip pressure across the jaw's range of motion. Self-cleaning threads keep the adjustment mechanism clear of debris during use, reducing downtime on the job. Licensed plumbers, pipefitters, and HVAC technicians are the primary users of this tool.

This wrench is suited for residential and light commercial work where compact tool access is required. The 6-inch overall length makes it practical in tight spaces such as under-sink rough-in, appliance connections, and close-quarter pipe fitting. The replaceable hook and heel jaws extend service life without requiring full tool replacement, making it a cost-effective option for service trucks and shop use alike.

Key Features

• Cast-iron housing and I-beam handle for rigid, durable construction
• Full floating forged hook jaw provides consistent, secure grip on pipe
• Self-cleaning threads prevent debris buildup in the jaw adjustment mechanism
• Replaceable hook and heel jaws extend tool service life
• Complies with federal specification GGG-W65IE, Type II, Class A
• Compact 6-inch overall length for work in confined spaces

Compatibility

Designed for use on pipe and round stock up to 3/4 inch in diameter. Compatible with standard straight pipe wrench replacement jaw sets designed for this tool series.

Installation Notes

This tool is used by licensed plumbers, pipefitters, and HVAC technicians during pipe assembly and removal. Always ensure the system is depressurized and supply valves are fully closed before breaking or making threaded pipe connections. Inspect the jaw teeth and adjustment threads before each use and replace worn jaw components as needed to maintain safe gripping force.

Technical Specifications

• Pipe Capacity: 3/4 inches
• Overall Length: 6 inches
• Handle Style: Straight I-beam
• Housing Material: Cast iron
• Jaw Type: Full floating forged hook jaw with replaceable hook and heel jaws
• Weight: 0.44 pounds
• Federal Specification: GGG-W65IE, Type II, Class A
• Sold As: Each

Standard Information

• Brand: RIDGID
• Manufacturer Part Number: RIG31000
