Ridgid R31035 Pipe Wrench 5 Inch Capacity 26 Inch Oal

Product Description

The RIDGID R31035 is a heavy-duty straight pipe wrench built for demanding plumbing and pipefitting applications. The cast-iron housing and I-beam handle deliver the rigidity needed for high-torque work on large-diameter pipe. A full floating forged hook jaw adjusts smoothly and maintains grip under load. Self-cleaning threads keep the jaw mechanism free of debris during use. The hook and heel jaws are replaceable, extending the service life of the tool. At 26 inches overall length, this wrench generates the leverage required for 5-inch-capacity pipe work.

This wrench is suited for commercial and industrial plumbing, mechanical piping, and large-scale pipefitting jobs where pipe diameters up to 5 inches are common. Plumbers, pipefitters, and mechanical contractors working on water mains, gas distribution piping, and process piping will find this tool sized appropriately for the work. It is sold as a single unit and is designed for repeated, sustained use in the field or shop.

Key Features

• Cast-iron housing and I-beam handle provide rigidity under high-torque loading
• Full floating forged hook jaw maintains consistent grip across the capacity range
• Self-cleaning threads reduce jaw mechanism fouling during use
• Replaceable hook and heel jaws extend overall tool service life
• Complies with federal specifications GGG-W65IE, Type II, Class A
• 5-inch jaw capacity with 26-inch overall length for high-leverage applications

Compatibility

Designed as a standard straight pipe wrench for use on threaded and non-threaded pipe up to 5 inches in diameter across residential, commercial, and industrial plumbing and pipefitting applications.

Installation Notes

Install and remove pipe using proper jaw engagement — seat the heel jaw firmly on the pipe before applying torque. Power down or isolate any pressurized system before breaking or making threaded connections. Inspect hook and heel jaws for wear before use and replace when teeth show significant rounding. Licensed plumbers and pipefitters should follow applicable local codes, including IPC and IFGC requirements, when working on pressurized piping systems.

Technical Specifications

• Jaw Capacity: 5 inches
• Overall Length: 26 inches
• Weight: 19.57 pounds
• Handle Construction: I-beam
• Housing Material: Cast iron
• Jaw Type: Full floating forged hook jaw with replaceable hook and heel jaws
• Compliance: Federal Specification GGG-W65IE, Type II, Class A
• Sold As: Each

Standard Information

• Brand: RIDGID
• Manufacturer Part Number: R31035
